Android手机上用户操作模拟方法的研究与实现

MonkeyEvent ev = mEventSource.getNextEvent();
if (ev != null) {
int injectCode = ev.injectEvent(mWm, mAm, mVerbose);
}

    public int injectEvent(IWindowManager iwm, IActivityManager iam, int verbose)
{
if (mCmd != null)
{
//Execute the shell command
try {
java.lang.Process p = Runtime.getRuntime().exec(mCmd);
int status = p.waitFor();
System.err.println("// Shell command " + mCmd + " status was " + status);
} catch (Exception e) {
System.err.println("// Exception from " + mCmd + ":");
System.err.println(e.toString());
}
}
return MonkeyEvent.INJECT_SUCCESS;
       }[1]

for(int i=0; i<EV_MAX; i++)
{
       memset(devicePath, 0, sizeof(devicePath));
       memset(buf, 0, sizeof(buf));
       sprintf(devicePath, "/dev/input/event%d", i);
       //LOGI(LOG_TAG, devicePath);
       if ((fd = open(devicePath, O_RDONLY)) < 0)
       {
              LOGI(LOG_TAG, "Open device failed");
              //打开该文件失败，继续打开下一个
              continue;
       }
       // EVIOCGNAME参考input.h
       ioctl(fd, EVIOCGNAME(sizeof(buf)), buf);
       //根据设备的名称来查找
       if( strstr(buf, “touchscreen”))
       {
              memcpy(device->deviceName, buf, sizeof(buf));
              //找到了，把event文件的路径保留下来
              memcpy(device->devicePath, devicePath, sizeof(devicePath));、
}
}

//*******************
//在这之前用ioctl打开我们找到的 /dev/input/event*/ 文件
//获取ABS的设置信息,并根据ABS信息判断哪些Event是支持的
ioctl(fd, EVIOCGBIT(EV_ABS, sizeof(absBitmask)), absBitmask);
ioctl(fd, EVIOCGBIT(EV_KEY, sizeof(keyBitmask)), keyBitmask);
if( test_bit(ABS_MT_POSITION_X, absBitmask)
&& test_bit(ABS_MT_POSITION_Y, absBitmask))
{
       LOGI(LOG_TAG, "This input device is a multi-touch device");
       device->isMultiTouch = true;
       device->supportMTEvent->bPositionX = true;
       device->supportMTEvent->bPositionY = true;
       //以下开始判断哪些事件是被该设备支持的
       if( test_bit(ABS_MT_SLOT, absBitmask))
       {
              device->supportMTEvent->bSlot = true;
              LOGI(LOG_TAG, "ABS_MT_SLOT is supported");
       }
       ……
}else if (test_bit(BTN_TOUCH, keyBitmask)
              && test_bit(ABS_X, absBitmask)
              && test_bit(ABS_Y, absBitmask)){
       LOGI(LOG_TAG, "This input device is a single-touch device");
       device->isSingleTouch = true;
}

/***
*     该函数是用于判断某个触摸事件是否支持，如果支持我们就发送它
*     将判断放到这个函数是因为在touch和drag等函数就不用再去判断了
**/
int TouchUtil::sendTouchEvent(const int fd, const int eventId, const int value)
{
       if (fd <= 0)
       {
              return RET_ERROR;
       }
       switch(eventId)
       {
              case ABS_MT_SLOT:
                     if( touchDevice->supportMTEvent->bSlot)
                     {
                            writeEvent(fd, EV_ABS, ABS_MT_SLOT, value);
                     }
                     break;
              case ABS_MT_TOUCH_MAJOR:
                     if( touchDevice->supportMTEvent->bTouchMajor)
                     {
                            writeEvent(fd, EV_ABS, ABS_MT_TOUCH_MAJOR, value);
                     }
           ……
              default:
                     break;
       }
       return RET_OK;
}

       int TouchUtil::down(const int x, const int y, const int slot, const int trackintId)
{
       if(!isDeviceReady)
       {
              return RET_ERROR;
       }
       if( touchDevice->isMultiTouch)
       {
              int value = (rand() % 16) + 1;
              //按下一个点
              sendTouchEvent(fd, ABS_MT_SLOT, slot);
              sendTouchEvent(fd, ABS_MT_TRACKING_ID, trackintId);
              sendTouchEvent(fd, ABS_MT_POSITION_X, x);
              sendTouchEvent(fd, ABS_MT_POSITION_Y, y);
              sendTouchEvent(fd, ABS_MT_TOUCH_MAJOR, value);
              sendTouchEvent(fd, ABS_MT_TOUCH_MINOR, value);
              sendTouchEvent(fd, ABS_MT_WIDTH_MAJOR, value);
              sendTouchEvent(fd, ABS_MT_WIDTH_MINOR, value);
              sendTouchEvent(fd, ABS_MT_ORIENTATION, value);
              sendTouchEvent(fd, ABS_MT_TOOL_TYPE, BTN_TOOL_FINGER);
              sendTouchEvent(fd, ABS_MT_BLOB_ID, value);
              sendTouchEvent(fd, ABS_MT_PRESSURE, value);
              sendTouchEvent(fd, ABS_MT_DISTANCE, value);
              sendTouchEvent(fd, ABS_MT_TOOL_X, value);
              sendTouchEvent(fd, ABS_MT_TOOL_Y, value);
              sendTouchEvent(fd, SYN_MT_REPORT, 0);
              sendTouchEvent(fd, SYN_REPORT, 0);
       }else
       {
              writeEvent(fd, EV_ABS, ABS_X, x);
              writeEvent(fd, EV_ABS, ABS_Y, y);
              writeEvent(fd, EV_ABS, ABS_PRESSURE, 1);
              writeEvent(fd, EV_KEY, BTN_TOUCH, 1);
              writeEvent(fd, EV_SYN, SYN_REPORT, 0);
       }
       return RET_OK;
}

int TouchUtil::touch(const int x, const int y, const int interval)
{
       if(!isDeviceReady)
       {
              return RET_ERROR;
       }
       g_trackingID ++;
       down(x, y, 0, g_trackingID);
       usleep(interval);
       up(x, y, 0);
}
int TouchUtil::pan(const int fromX, const int fromY, const int toX, const int toY)
{
       if(!isDeviceReady)
       {
              return RET_ERROR;
       }
       char msg[128];
       memset(msg, 0, sizeof(msg));
       sprintf(msg, "pan(%d, %d, %d, %d)", fromX, fromY, toX, toY);
       LOGI(LOG_TAG, msg);
       g_trackingID ++;
       down(fromX, fromY, 0, g_trackingID);
       usleep(5);
       int deltaX = (toX - fromX) / 10;
       int deltaY = (toY - fromY) / 10;
       int tempX = fromX;
       int tempY = fromY;
       for(int i=0; i<9; i++)
       {
              tempX += deltaX;
              tempY += deltaY;
              pressAndMove(tempX, tempY, 0, g_trackingID);
              usleep(5);
       }
       up(toX, toY, 0);
       return      RET_OK;
}
