使用SPDK实现NVMe over Fabrics Target

本文使用两台PC，一台做NVMe over Fabrics Target（服务端），一台做NVMe over Fabrics initiator（客户端）。首先使用SoftRoCE来实现底层的rdma传输，然后使用SPDK来实现NVMe over Fabrics Target。

一.首先使用SoftRoCE来实现rdma

服务端和客户端都是：CentOS-7-x86_64-DVD-1810

服务端和客户端都要load softRoCE的kernel模块：rdma_rxe

服务端

# rxe_cfg start

# rxe_cfg add enp5s0f0

# rxe_cfg status

客户端

# rxe_cfg start

# rxe_cfg add enp1s0f0

# rxe_cfg status

测试

服务端

# iptables -F

# rping -s -a 192.168.80.100 -v -C 1000

客户端

# rping -c -a 192.168.80.100 -v -C 1000

二.SPDK nvmf-tgt环境搭建

参考：https://spdk.io/doc/nvmf.html

服务端

1.确定NVME物理设备

[root@localhost ~]# lspci

01:00.0 Non-Volatile memory controller: Intel Corporation PCIe Data Center SSD (rev 01)

2.编译spdk

git clone https://github.com/spdk/spdk

cd spdk

git submodule update --init

scripts/pkgdep.sh

./configure --with-rdma

make

3.启动NVMe-oF target

# modprobe nvme_rdma

# scripts/setup.sh

setup会把nvme盘的驱动由nvme改为uio_pci_generic

# build/bin/nvmf_tgt &

# scripts/rpc.py nvmf_create_transport -t RDMA -u 8192 -p 4 -c 0

4.通过rpc创建导出bdev

创建内存测试盘

# scripts/rpc.py bdev_malloc_create -b Malloc0 512 512 #scripts/rpc.py nvmf_create_subsystem nqn.2016-06.io.spdk:cnode1 -a -s SPDK00000000000001 -d SPDK_Controller1 # scripts/rpc.py nvmf_subsystem_add_ns nqn.2016-06.io.spdk:cnode1 Malloc0 # scripts/rpc.py nvmf_subsystem_add_listener nqn.2016-06.io.spdk:cnode1 -t rdma -a 192.168.80.100 -s 4420

创建nvme盘

# scripts/rpc.py bdev_nvme_attach_controller -b Nvme0 -t PCIe -a 0000:01:00.0 # scripts/rpc.py nvmf_create_subsystem nqn.2016-06.io.spdk:cnode2 -a -s SPDK00000000000002 -d SPDK_Controller1 # scripts/rpc.py nvmf_subsystem_add_ns nqn.2016-06.io.spdk:cnode2 Nvme0n1 # scripts/rpc.py nvmf_subsystem_add_listener nqn.2016-06.io.spdk:cnode2 -t rdma -a 192.168.80.100 -s 4420

客户端

1.load module

# modprobe nvme-rdma

2.discovery

# nvme discover -t rdma -a 192.168.80.100 -s 4420

3.connect

连接cnode1

# nvme connect -t rdma -n "nqn.2016-06.io.spdk:cnode1" -a 192.168.80.100 -s 4420

连接cnode2

# nvme connect -t rdma -n "nqn.2016-06.io.spdk:cnode2" -a 192.168.80.100 -s 4420

# lsblk

4.disconnect

# nvme disconnect -n "nqn.2016-06.io.spdk:cnode1"

# nvme disconnect -n "nqn.2016-06.io.spdk:cnode2"
