R-ggTimeSeries | ggplot2: 热力日历图

数据小磨坊

发布于 2020-09-10 08:52:32

2.5K00

代码可运行

文章被收录于专栏：数据小魔方数据小魔方

运行总次数：0

代码可运行

我们平常的日历也可以当作可视化工具，适用于显示不同时间段，以及活动事件的组织情况。时间段通常以不同单位显示，例如日、周、月和年。今天我们最常用的日历形式是公历，每个月份的月历由7个垂直列组成（代表每周7天），如图所示。

日历图的主要可视化形式有如图6-2-2所示的两种：以年为单位的日历图（见图6-2-2 (a)）和以月为单位的日历图（见图6-2-2 (b)）。日历图的数据结构一般为(Date,Value)，将Value按照Date（日期）在日历上展示，其中Value映射到颜色。

1. ggTimeSeries绘图

R中ggTimeSeries 包[1]的ggplot_calendar_heatmap()函数可以绘制如图6-2-2(a)所示的日历图，但是不能设定日历图每个时间单元的边框格式。

使用stat_calendar_heatmap()函数和ggplot2包的ggplot()函数可以调整日历图每个时间单元的边框格式，具体代码如下所示。其关键是使用as.integer(strftime())日期型处理组合函数获取某天对应所在的年份、月份、周数等数据信息。

#setwd("D:/R/working_documents1")
library(ggplot2)
library(data.table) # 数据格式依赖
library(ggTimeSeries)
library(RColorBrewer)

# 构造随机数据
set.seed(2134)
dat <- data.table(
  date = seq(as.Date("2016-01-01"), as.Date("2019-12-31"), "days"),
  ValueCol = runif(1461)
)

dat[, ValueCol := ValueCol + (strftime(date, "%u") %in% c(6,7)*runif(1)*0.75)
    ][, ValueCol := ValueCol + (abs(as.numeric(strftime(date, "%m")) - 6.5))*runif(1)*0.75
      ][, ':='(Year = as.integer(strftime(date, "%Y")), # add new column
               month = as.integer(strftime(date, "%m")),
               week = as.integer(strftime(date, "%W")))] # 添加列

MonthLabels <- dat[, list(meanWkofYr = mean(week)), by = c("month")
                   ][, month := month.abb[month]]

ggplot(data = dat, aes(date = date, fill = ValueCol)) +
  stat_calendar_heatmap() +
  scale_fill_gradientn(colours = rev(brewer.pal(11, "Spectral"))) +
  scale_y_continuous(name = NULL,
                     breaks = seq(7, 1, -1),
                     labels = c("Mon", "Tue", "Wed",
                                "Thu", "Fri", "Sat", "Sun")) +
  scale_x_continuous(name = NULL,
                     breaks = MonthLabels$meanWkofYr,
                     labels = MonthLabels$month,
                     expand = c(0,0)) +
  facet_wrap(~Year, ncol = 1, strip.position = "right") +
  theme(panel.background = element_blank(),
        panel.border = element_blank(),
        strip.background = element_blank(),
        strip.text = element_text(size = 13, face = "plain", color = "black"),
        axis.line = element_line(colour = "black", size = 0.25),
        axis.title = element_text(size = 10, face = "plain", color = "black"),
        axis.text = element_text(size = 10, face = "plain", color = "black"))

2.geom_tile()

使用R中ggplot2包的geom_tile()函数，借助facet_wrap()函数分面，就可以绘制如图6-2-2(b)所示的以月为单位的日历图，具体代码如下所示。

label_mons <- c("Jan", "Feb", "Mar", "Apr", "May", "Jun", "Jul",
                "Aug", "Sep", "Oct", "Nov", "Dec")
label_wik <- c("Mon", "Tue", "Wed", "Thu", "Fri", "Sat", "Sun")

dat19 <- dat[Year == 2017, list(date, ValueCol, month, week)
             ][, ':='(weekday = as.integer(strftime(date, "%u")), # 周数
                      yearmonth = strftime(date, "%m%Y"),       # 月数
                      day = strftime(date, "%d"))              # 天数
               ][, ':='(monthf = factor(x = month, levels = as.character(1:12),
                                      labels = label_mons, ordered = TRUE),
                        weekdayf = factor(x = weekday, levels = 1:7,
                                           labels = label_wik, ordered = TRUE),
                        yearmonthf = factor(x = yearmonth))
                 ][, ':='(monthweek = 1 + week - min(week)), by = .(monthf)] # 分组聚合

label_mons <- c("Jan", "Feb", "Mar", "Apr", "May", "Jun", "Jul",
                "Aug", "Sep", "Oct", "Nov", "Dec")
label_wik <- c("Mon", "Tue", "Wed", "Thu", "Fri", "Sat", "Sun")

dat19 <- dat[Year == 2017, list(date, ValueCol, month, week)
             ][, ':='(weekday = as.integer(strftime(date, "%u")), # 周数
                      day = strftime(date, "%d"))              # 天数
               ][, ':='(monthf = factor(x = month, levels = as.character(1:12),
                                      labels = label_mons, ordered = TRUE),
                        weekdayf = factor(x = weekday, levels = 1:7,
                                           labels = label_wik, ordered = TRUE))
                 ][, ':='(monthweek = 1 + week - min(week)), by = .(monthf)] # 分组聚合

ggplot(dat19, aes(weekdayf, monthweek, fill = ValueCol)) +
  geom_tile(color = "white") +
  geom_text(aes(label = day), size = 3) +
  scale_fill_gradientn(colours = rev(brewer.pal(11, "Spectral"))) +
  facet_wrap(~monthf, nrow = 3) +
  scale_y_reverse(name = "Week of the month") +
  xlab("Day") +
  theme(strip.text = element_text(size = 11, face = "plain", color = "black"),
        panel.grid = element_blank())
