一、部署概述
1.官方建议使用CentOS 6 或 CentOS 7，部署脚本只在这两个发行版上试验过。
2.资源要求
资源 | 描述 |
|---|---|
内存要求 | 至少为 OBServer 配置 8G 内存。 |
磁盘要求 | 需要为 OBServer 准备一个工作目录，这个目录所在的磁盘至少要有 20G 的剩余空间，并且磁盘使用率要低于 80%。 |
3.软件要求
软件 | 版本 |
|---|---|
Python | Python 2.7 及以上 |
二、部署前准备
部署一台8G内存，50G磁盘空间，单网卡（hostonly模式）的centos7的服务器。
1.前期配置
--查看内核
[root@octa ~]# uname -a
Linux octa 3.10.0-957.el7.x86_64 #1 SMP Thu Nov 8 23:39:32 UTC 2018 x86_64 x86_64 x86_64 GNU/Linux
[root@octa ~]# cat /etc/redhat-release
CentOS Linux release 7.6.1810 (Core)
--查看内存
[root@octa ~]# free -m
total used free shared buff/cache available
Mem: 7886 134 7643 8 109 7556
Swap: 5119 0 5119
--设置主机名
hostnamectl set-hostname obca
--关闭防火墙
systemctl stop firewalld
systemctl disable firewalld
--关闭selinux
vi /etc/selinux/config
disabled
--配置网络
nmcli con mod ens0p3 ipv4.address 192.168.56.100/24 ipv4.method manual autoconnect yes
--新建目录
mkdir /soft
mkdir /ob2.下载试用版oceanbase安装包
- 在 OceanBase 官网顶部导航栏，选择 资源 > 下载， 进入资源下载页面。
- 单击 安装包下载，系统会跳转到 OceanBase 社区登录页面。
- 输入您的用户名和密码，进行登录。 如果您还未注册 OceanBase 社区账号，请按照提示完成注册，并登录。
- 在弹出的对话框中，勾选 我已阅读并遵守《OceanBase 软件试用许可协议》，然后单击 下载安装包。 OceanBase 试用版的安装介质开始下载，下载的安装介质中包含部署脚本（ob-deploy.tar）。
三、安装部署
1.解压安装包
[root@octa soft]# cd /soft/
[root@octa soft]# tar -xvf ob-deploy.tar
[root@octa soft]# ls
ob-deploy ob-deploy.tar2.修改默认配置
[root@octa soft]# cd ob-deploy
[root@octa ob-deploy]# ls
admin config.py features.md init.sql install mysql plugin_dir tools
b deploy.dockerfile h init_user_oracle.sql lib mysql_example README.md
bin etc hap.py init_user.sql Makefile oracle_example sysbench
--配置observer启动目录home = '/ob'
[root@octa ob-deploy]# vi config.py
[root@octa ob-deploy]# cat config.py
load('obi,obt-patch,mini-mode,sample-db,sysbench')
if not indocker():
home = '/ob'
obs_cfg.update(mini_mode_cfg)
obs_cfg.update(system_memory='5G', memory_limit='8G', datafile_size='10G')
# 定义一个单server的ob集群，mysql端口号2881，rpc端口号2882
ob1 = OBI('127.0.0.1:2882:2881')
# 定义另一个单server的ob集群，mysql端口号/rpc端口号由uid hash生成
ob2 = OBI('127.0.0.1')
# 单个机器上起3个observer
ob3 = OBI('127.0.0.1@[z1,z2,z3]', dev='lo', is_local=True)3.初始化 OceanBase 实例（整个初始化过程大概需要一分钟时间）
[root@octa ob-deploy]# ./hap.py ob1.reboot
2021-02-26 22:19:26.454790 call.py:3 CALL: top make_local_etc_dir
2021-02-26 22:19:26.468489 call.py:3 CALL: top ob1.reboot
2021-02-26 22:19:26.471535 call.py:3 CALL: top.ob1 local_reboot
2021-02-26 22:19:26.475062 call.py:3 CALL: top.ob1 force_stop
2021-02-26 22:19:26.478799 call.py:3 CALL: top.ob1 stop
2021-02-26 22:19:26.482765 call.py:3 CALL: top.ob1 all_server
2021-02-26 22:19:26.489389 call.py:3 CALL: top.ob1.obs0 stop
2021-02-26 22:19:26.498137 magic_ctrl.py:3 retry_loop: retryloop: timeout=10 interval = 0.1
2021-02-26 22:19:26.507174 magic_ctrl.py:6 retry_loop: #### tryloop try_stop ####
2021-02-26 22:19:26.514685 call.py:3 CALL: top.ob1.obs0 try_stop
2021-02-26 22:19:26.551222 magic_ctrl.py:9 retry_loop: #### tryloop success ####
2021-02-26 22:19:26.561633 call.py:3 CALL: top.ob1 sleep
2021-02-26 22:19:26.581256 misc-deps.py:34 sleep: sleep 3
2021-02-26 22:19:29.591045 call.py:3 CALL: top.ob1 cleanup
2021-02-26 22:19:29.595084 call.py:3 CALL: top.ob1 all_server
2021-02-26 22:19:29.599943 call.py:3 CALL: top.ob1.obs0 rmdir
2021-02-26 22:19:29.613990 call.py:3 CALL: top.ob1 mk_local_dir
2021-02-26 22:19:29.621781 call.py:3 CALL: top.ob1 mkdir
2021-02-26 22:19:29.626262 call.py:3 CALL: top.ob1 all_server
2021-02-26 22:19:29.631620 call.py:3 CALL: top.ob1.obs0 mkdir
2021-02-26 22:19:29.671123 call.py:3 CALL: top.ob1 local_sync
2021-02-26 22:19:29.676008 call.py:3 CALL: top.ob1 all_server
2021-02-26 22:19:29.681570 call.py:3 CALL: top.ob1.obs0 local_sync
2021-02-26 22:19:30.411532 call.py:3 CALL: top.ob1 prepare_proxy_cfg
2021-02-26 22:19:30.414379 call.py:3 CALL: top.ob1 start_servers
2021-02-26 22:19:30.419056 call.py:3 CALL: top.ob1 all_observer
2021-02-26 22:19:30.424605 call.py:3 CALL: top.ob1.obs0 start
/ob/ob1.obs0/bin/observer -P 2882 -p 2881 -z test -n ob1.root -c 1 -d /ob/ob1.obs0/store -l INFO -i lo -r 127.0.0.1:2882:2881 -o memory_limit=8G,cache_wash_threshold=1G,row_purge_thread_count=1,net_thread_count=1,enable_syslog_recycle=True,enable_merge_by_turn=FALSE,cpu_count=16,location_refresh_thread_count=2,max_syslog_file_count=3,major_freeze_duty_time=Disable,__easy_memory_limit=1G,schema_history_expire_time=1d,merge_thread_count=1,writing_throttling_trigger_percentage=70,_max_trx_size=2M,workers_per_cpu_quota=2,enable_separate_sys_clog=0,datafile_disk_percentage=50,__min_full_resource_pool_memory=536870912,system_memory=5G,memory_chunk_cache_size=128M,trace_log_slow_query_watermark=10s,writing_throttling_maximum_duration=1m,switchover_process_thread_count=1,datafile_size=10G,minor_freeze_times=500,stack_size=1536K,disk_io_thread_coun=1
rpc port: 2882
mysql port: 2881
zone: test
appname: ob1.root
cluster id: 1
data_dir: /ob/ob1.obs0/store
log level: INFO
devname: lo
rs list: 127.0.0.1:2882:2881
optstr: memory_limit=8G,cache_wash_threshold=1G,row_purge_thread_count=1,net_thread_count=1,enable_syslog_recycle=True,enable_merge_by_turn=FALSE,cpu_count=16,location_refresh_thread_count=2,max_syslog_file_count=3,major_freeze_duty_time=Disable,__easy_memory_limit=1G,schema_history_expire_time=1d,merge_thread_count=1,writing_throttling_trigger_percentage=70,_max_trx_size=2M,workers_per_cpu_quota=2,enable_separate_sys_clog=0,datafile_disk_percentage=50,__min_full_resource_pool_memory=536870912,system_memory=5G,memory_chunk_cache_size=128M,trace_log_slow_query_watermark=10s,writing_throttling_maximum_duration=1m,switchover_process_thread_count=1,datafile_size=10G,minor_freeze_times=500,stack_size=1536K,disk_io_thread_coun=1
2021-02-26 22:19:30.518636 call.py:3 CALL: top.ob1 bootstrap
2021-02-26 22:19:30.524717 magic_ctrl.py:3 retry_loop: retryloop: timeout=864000 interval = 1
2021-02-26 22:19:30.528981 magic_ctrl.py:6 retry_loop: #### tryloop obs0.bootstrap ####
2021-02-26 22:19:30.533487 call.py:3 CALL: top.ob1 obs0.bootstrap
ERROR 2003 (HY000): Can't connect to MySQL server on '127.0.0.1' (111)
2021-02-26 22:19:30.624556 magic_ctrl.py:12 retry_loop: tryloop fail: Fail: shell fail: ./mysql --prompt "OceanBase(\u@\d)>" -h 127.0.0.1 -P 2881 -uroot input="alter system bootstrap REGION 'sys_region' ZONE 'test' SERVER '127.0.0.1:2882'; # ExceptionOnFail DiscardXOutput" ret=1
2021-02-26 22:19:31.633175 magic_ctrl.py:6 retry_loop: #### tryloop obs0.bootstrap ####
2021-02-26 22:19:31.637507 call.py:3 CALL: top.ob1 obs0.bootstrap
ERROR 2003 (HY000): Can't connect to MySQL server on '127.0.0.1' (111)
2021-02-26 22:19:31.694000 magic_ctrl.py:12 retry_loop: tryloop fail: Fail: shell fail: ./mysql --prompt "OceanBase(\u@\d)>" -h 127.0.0.1 -P 2881 -uroot input="alter system bootstrap REGION 'sys_region' ZONE 'test' SERVER '127.0.0.1:2882'; # ExceptionOnFail DiscardXOutput" ret=1
2021-02-26 22:19:32.700971 magic_ctrl.py:6 retry_loop: #### tryloop obs0.bootstrap ####
2021-02-26 22:19:32.705280 call.py:3 CALL: top.ob1 obs0.bootstrap
ERROR 2003 (HY000): Can't connect to MySQL server on '127.0.0.1' (111)
2021-02-26 22:19:32.807480 magic_ctrl.py:12 retry_loop: tryloop fail: Fail: shell fail: ./mysql --prompt "OceanBase(\u@\d)>" -h 127.0.0.1 -P 2881 -uroot input="alter system bootstrap REGION 'sys_region' ZONE 'test' SERVER '127.0.0.1:2882'; # ExceptionOnFail DiscardXOutput" ret=1
2021-02-26 22:19:33.812714 magic_ctrl.py:6 retry_loop: #### tryloop obs0.bootstrap ####
2021-02-26 22:19:33.817042 call.py:3 CALL: top.ob1 obs0.bootstrap
2021-02-26 22:20:45.174806 magic_ctrl.py:9 retry_loop: #### tryloop success ####
2021-02-26 22:20:45.179920 call.py:3 CALL: top.ob1 post_bootstrap
2021-02-26 22:20:45.184520 call.py:3 CALL: top.ob1 wait_service
2021-02-26 22:20:45.199348 magic_ctrl.py:3 retry_loop: retryloop: timeout=864000 interval = 1
2021-02-26 22:20:45.203777 magic_ctrl.py:6 retry_loop: #### tryloop obs0.wait_service ####
2021-02-26 22:20:45.362713 call.py:3 CALL: top.ob1 obs0.wait_service
2021-02-26 22:20:45.613934 magic_ctrl.py:9 retry_loop: #### tryloop success ####
2021-02-26 22:20:45.618807 call.py:3 CALL: top.ob1 exec_init_sql
2021-02-26 22:20:45.622290 call.py:3 CALL: top.ob1 obs0.sql
2021-02-26 22:21:05.838187 call.py:3 CALL: top.ob1 add_server
2021-02-26 22:21:05.842090 call.py:3 CALL: top.ob1 all_obs
2021-02-26 22:21:05.847035 call.py:3 CALL: top.ob1 exec_init_user_sql1
2021-02-26 22:21:05.941993 call.py:3 CALL: top.ob1 exec_init_user_sql2
2021-02-26 22:21:05.945515 call.py:3 CALL: top.ob1 obs0.mysql
2021-02-26 22:21:06.904660 call.py:3 CALL: top.ob1 start_proxy
2021-02-26 22:21:06.909666 call.py:3 CALL: top.ob1 all_proxy
2021-02-26 22:21:06.914466 call.py:3 CALL: top.ob1 check_bootstrap
2021-02-26 22:21:06.943952 call.py:3 CALL: top.ob1 obs0.check_bootstrap
[('force_stop', [('obs0.stop', 'succ')]),
('sleep', None),
('cleanup', [('obs0.rmdir', 0)]),
('mk_local_dir', 0),
('mkdir', [('obs0.mkdir', 0)]),
('local_sync', [('obs0.local_sync', 0)]),
('prepare_proxy_cfg', 'skip'),
('start_servers', [('obs0.start', 0)]),
('bootstrap', 'succ'),
('post_bootstrap', None),
('wait_service', 'succ'),
('exec_init_sql', 0),
('add_server', []),
('exec_init_user_sql1', 'skip'),
('exec_init_user_sql2', 0),
('start_proxy', []),
('check_bootstrap', 0)]
初始化 OceanBase 实例成功之后，会自动创建两个租户，sys 租户和一个普通的 mysql 租户。4.部署后验证
--通过 MySQL 客户端连接 OceanBase 数据库
[root@octa ob-deploy]# ./hap.py ob1.obmysql
2021-02-26 22:22:56.870359 call.py:3 CALL: top make_local_etc_dir
2021-02-26 22:22:56.884471 call.py:3 CALL: top ob1.obmysql
2021-02-26 22:22:56.886940 call.py:3 CALL: top.ob1 sql
2021-02-26 22:22:56.889862 call.py:3 CALL: top.ob1 obs0.sql
Reading table information for completion of table and column names
You can turn off this feature to get a quicker startup with -A
Welcome to the MariaDB monitor. Commands end with ; or \g.
Your MySQL connection id is 3221488235
Server version: 5.7.25 OceanBase 2.2.50 (r1-1c6441e8fb858c80da395f934f67ed305425864e) (Built Mar 6 2020 18:41:01)
Copyright (c) 2000, 2018, Oracle, MariaDB Corporation Ab and others.
Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.
OceanBase(root@oceanbase)>show databases;
+--------------------+
| Database |
+--------------------+
| oceanbase |
| information_schema |
| mysql |
| SYS |
| LBACSYS |
| ORAAUDITOR |
| test |
+--------------------+
7 rows in set (0.00 sec)
OceanBase(root@oceanbase)>use oceanbase;
Database changed
OceanBase(root@oceanbase)>show tables;
+-----------------------------------------+
| Tables_in_oceanbase |
+-----------------------------------------+
| __all_acquired_snapshot |
| __all_backup_clean_info_history |
| __all_backup_log_archive_status_history |
| __all_backup_task_clean_history |
| __all_backup_task_history |
| __all_build_index_param |
| __all_charset |
| __all_clog_history_info |
| __all_clog_history_info_v2 |
| __all_cluster |
| __all_coll_type |
| __all_coll_type_history |
| __all_collation |
| __all_column |
| __all_column_history |
| __all_column_stat |
| __all_column_statistic |
| __all_constraint |
| __all_constraint_history |
| __all_core_table |
| __all_database |
| __all_database_history |
| __all_database_privilege |
| __all_database_privilege_history |
| __all_dblink |
| __all_dblink_history |
| __all_ddl_helper |
| __all_ddl_id |
| __all_ddl_operation |
| __all_def_sub_part |
| __all_def_sub_part_history |
| __all_dummy |
| __all_election_event_history |
| __all_failover_info |
| __all_failover_scn |
| __all_foreign_key |
| __all_foreign_key_column |
| __all_foreign_key_column_history |
| __all_foreign_key_history |
| __all_freeze_schema_version |
| __all_frozen_map |
| __all_func |
| __all_func_history |
| __all_global_index_data_src |
| __all_gts |
| __all_histogram_stat |
| __all_immediate_effect_index_sstable |
| __all_index_build_stat |
| __all_index_checksum |
| __all_index_schedule_task |
| __all_index_wait_transaction_status |
| __all_local_index_status |
| __all_meta_table |
| __all_ori_schema_version |
| __all_outline |
| __all_outline_history |
| __all_package |
| __all_package_history |
| __all_part |
| __all_part_history |
| __all_part_info |
| __all_part_info_history |
| __all_partition_member_list |
| __all_plan_baseline |
| __all_plan_baseline_history |
| __all_privilege |
| __all_recyclebin |
| __all_resource_pool |
| __all_restore_info |
| __all_restore_job |
| __all_restore_job_history |
| __all_restore_task |
| __all_root_table |
| __all_rootservice_event_history |
| __all_rootservice_job |
| __all_routine |
| __all_routine_history |
| __all_routine_param |
| __all_routine_param_history |
| __all_seed_parameter |
| __all_sequence |
| __all_sequence_object |
| __all_sequence_object_history |
| __all_sequence_v2 |
| __all_sequence_value |
| __all_server |
| __all_server_event_history |
| __all_sql_execute_task |
| __all_sstable_checksum |
| __all_sstable_column_checksum |
| __all_sub_part |
| __all_sub_part_history |
| __all_synonym |
| __all_synonym_history |
| __all_sys_parameter |
| __all_sys_stat |
| __all_sys_variable |
| __all_sys_variable_history |
| __all_table |
| __all_table_history |
| __all_table_privilege |
| __all_table_privilege_history |
| __all_table_stat |
| __all_tablegroup |
| __all_tablegroup_history |
| __all_temp_table |
| __all_tenant |
| __all_tenant_backup_clean_info |
| __all_tenant_backup_info |
| __all_tenant_backup_log_archive_status |
| __all_tenant_backup_task |
| __all_tenant_gc_partition_info |
| __all_tenant_gts |
| __all_tenant_history |
| __all_tenant_keystore |
| __all_tenant_keystore_history |
| __all_tenant_meta_table |
| __all_tenant_ols_component |
| __all_tenant_ols_component_history |
| __all_tenant_ols_label |
| __all_tenant_ols_label_history |
| __all_tenant_ols_policy |
| __all_tenant_ols_policy_history |
| __all_tenant_ols_user_level |
| __all_tenant_ols_user_level_history |
| __all_tenant_partition_meta_table |
| __all_tenant_pg_backup_task |
| __all_tenant_plan_baseline |
| __all_tenant_plan_baseline_history |
| __all_tenant_profile |
| __all_tenant_profile_history |
| __all_tenant_resource_usage |
| __all_tenant_role_grantee_map |
| __all_tenant_role_grantee_map_history |
| __all_tenant_security_audit |
| __all_tenant_security_audit_history |
| __all_tenant_security_audit_record |
| __all_tenant_sstable_column_checksum |
| __all_tenant_tablespace |
| __all_tenant_tablespace_history |
| __all_tenant_trigger |
| __all_tenant_trigger_history |
| __all_tenant_user_failed_login_stat |
| __all_time_zone |
| __all_time_zone_name |
| __all_time_zone_transition |
| __all_time_zone_transition_type |
| __all_type |
| __all_type_attr |
| __all_type_attr_history |
| __all_type_history |
| __all_unit |
| __all_unit_config |
| __all_unit_load_history |
| __all_user |
| __all_user_history |
| __all_weak_read_service |
| __all_zone |
| __tenant_parameter |
| gv$concurrent_limit_sql |
| gv$database |
| gv$latch |
| gv$lock_wait_stat |
| gv$memory |
| gv$memstore |
| gv$memstore_info |
| gv$minor_merge_info |
| gv$ob_sql_workarea_memory_info |
| gv$obrpc_incoming |
| gv$obrpc_outgoing |
| gv$outline |
| gv$partition |
| gv$partition_audit |
| gv$plan_cache_plan_explain |
| gv$plan_cache_plan_stat |
| gv$plan_cache_reference_info |
| gv$plan_cache_stat |
| gv$ps_item_info |
| gv$ps_stat |
| gv$server_memstore |
| gv$session_event |
| gv$session_longops |
| gv$session_wait |
| gv$session_wait_history |
| gv$sesstat |
| gv$sql |
| gv$sql_audit |
| gv$sql_monitor |
| gv$sql_plan_monitor |
| gv$sql_plan_statistics |
| gv$sql_workarea |
| gv$sql_workarea_active |
| gv$sql_workarea_histogram |
| gv$sysstat |
| gv$system_event |
| gv$table |
| gv$tenant |
| gv$tenant_memstore_allocator_info |
| gv$tenant_px_worker_stat |
| gv$tenant_sequence_object |
| gv$unit |
| gv$unit_load_balance_event_history |
| v$event_name |
| v$latch |
| v$lock_wait_stat |
| v$memory |
| v$memstore |
| v$memstore_info |
| v$minor_merge_info |
| v$ob_backup_archivelog_process |
| v$ob_backup_archivelog_summary |
| v$ob_backup_job_details |
| v$ob_backup_process |
| v$ob_backup_set_details |
| v$ob_backup_set_expired |
| v$ob_cluster |
| v$ob_cluster_event_history |
| v$ob_cluster_stats |
| v$ob_sql_workarea_memory_info |
| v$ob_standby_status |
| v$ob_timestamp_service |
| v$obrpc_incoming |
| v$obrpc_outgoing |
| v$partition |
| v$partition_audit |
| v$plan_cache_plan_explain |
| v$plan_cache_plan_stat |
| v$plan_cache_reference_info |
| v$plan_cache_stat |
| v$ps_item_info |
| v$ps_stat |
| v$session_event |
| v$session_longops |
| v$session_wait |
| v$session_wait_history |
| v$sesstat |
| v$sql |
| v$sql_audit |
| v$sql_monitor |
| v$sql_plan_monitor |
| v$sql_plan_statistics |
| v$sql_workarea |
| v$sql_workarea_active |
| v$sql_workarea_histogram |
| v$statname |
| v$sysstat |
| v$system_event |
| v$tenant_memstore_allocator_info |
| v$tenant_px_worker_stat |
| v$unit |
+-----------------------------------------+
250 rows in set (0.00 sec)本文参与 腾讯云自媒体同步曝光计划，分享自作者个人站点/博客。
原始发表：2021/02/26 ，如有侵权请联系 cloudcommunity@tencent.com 删除
评论
登录后参与评论
暂无评论
推荐阅读
编辑精选文章
换一批
推荐阅读
相关推荐
OceanBase 社区版OBD部署示例主副本
更多 >
腾讯云开发者
