本篇内容有点长，代码有点多。有兴趣的可以坚持看下去，并动手实践，没兴趣的可以划走。本文分两大块，一是搞清楚prometheus四种类型的指标Counter，Gauge，Histogram，Summary用golang语言如何构造这4种类型对应的指标，二是搞清楚修改指标值的场景和方式。

指标类型	类别	描述	可应用场景
Counter	计数类	使用在累计指标单调递增或递减情况下，只能在目标重启后自动归零	服务请求处理数量、已完成任务数量、错误数量
Guage	测量类	使用可增可减的的数据情况下	当前内存/CPU使用情况、并发请求数量
Histogram	直方图类	使用统计指标信息在不同区间内的统计数量	延迟时间、响应大小。例如：0-1秒内的延迟时间、、0-5秒内的延迟时间、例如0-1kb之内的响应大小、0-5kb之内的响应大小
Summary	摘要类	类似于直方图，在客户端对百分位进行统计	延迟时间、响应大小。例如：超过百分之多少的人要满足需求的话，需要多长时间完成。

1. Gauge指标类型

1.1 不带label的基本例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 cpuUsage := prometheus.NewGauge(prometheus.GaugeOpts{
  Name: "cpu_usage",                      // 指标名称
  Help: "this is test metrics cpu usage", // 帮助信息
 })
 // 给指标设置值
 cpuUsage.Set(89.56)
 // 注册指标
 prometheus.MustRegister(cpuUsage)
 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

1.2 带有固定label指标的例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 cpuUsage := prometheus.NewGauge(prometheus.GaugeOpts{
  Name:        "cpu_usage",                      // 指标名称
  Help:        "this is test metrics cpu usage", // 帮助信息
  ConstLabels: prometheus.Labels{"MachineType": "host"}, // label
 })
 // 给指标设置值
 cpuUsage.Set(89.56)
 // 注册指标
 prometheus.MustRegister(cpuUsage)
 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

1.3 带有非固定label指标的例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 //定义带有不固定label的指标
 mtu := prometheus.NewGaugeVec(prometheus.GaugeOpts{
  Name: "interface_mtu",
  Help: "网卡接口MTU",
 }, []string{"interface", "Machinetype"})

 // 给指标设置值
 mtu.WithLabelValues("lo", "host").Set(1500)
 mtu.WithLabelValues("ens32", "host").Set(1500)
 mtu.WithLabelValues("eth0", "host").Set(1500)

 // 注册指标
 prometheus.MustRegister(mtu)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

2. Counter指标类型

2.1 不带label的基本例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 reqTotal := prometheus.NewCounter(prometheus.CounterOpts{
  Name: "current_request_total",
  Help: "当前请求总数",
 })
 // 注册指标
 prometheus.MustRegister(reqTotal)

 // 设置值
 reqTotal.Add(10)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

2.2 带有固定label指标的例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 suceReqTotal := prometheus.NewCounter(prometheus.CounterOpts{
  Name:        "sucess_request_total",
  Help:        "请求成功的总数",
  ConstLabels: prometheus.Labels{"StatusCode": "200"},
 })
 // 注册指标
 prometheus.MustRegister(suceReqTotal)

 // 设置值
 suceReqTotal.Add(5675)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

2.3 带有非固定label指标的例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 pathReqTotal := prometheus.NewCounterVec(prometheus.CounterOpts{
  Name: "path_request_total",
  Help: "path请求总数",
 }, []string{"path"})
 // 注册指标
 prometheus.MustRegister(pathReqTotal)

 // 设置值
 pathReqTotal.WithLabelValues("/token").Add(37)
 pathReqTotal.WithLabelValues("/auth").Add(23)
 pathReqTotal.WithLabelValues("/user").Add(90)
 pathReqTotal.WithLabelValues("/api").Add(67)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

3. Histogram指标类型

3.1 不带label的基本例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 reqDelay := prometheus.NewHistogram(prometheus.HistogramOpts{
  Name:    "request_delay",
  Help:    "请求延迟，单位秒",
  Buckets: prometheus.LinearBuckets(0, 3, 6), // 调用LinearBuckets生成区间，从0开始，宽度3，共6个Bucket
 })

 // 注册指标
 prometheus.MustRegister(reqDelay)

 // 设置值
 reqDelay.Observe(6)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

3.2 带固定label的例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 reqDelay := prometheus.NewHistogram(prometheus.HistogramOpts{
  Name:        "request_delay",
  Help:        "请求延迟，单位秒",
  Buckets:     prometheus.LinearBuckets(0, 3, 6), // 调用LinearBuckets生成区间，从0开始，宽度3，共6个Bucket
  ConstLabels: prometheus.Labels{"path": "/api"},
 })

 // 注册指标
 prometheus.MustRegister(reqDelay)

 // 设置值
 reqDelay.Observe(6)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

3.3 带有非固定label的例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 reqDelay := prometheus.NewHistogramVec(prometheus.HistogramOpts{
  Name:    "request_delay",
  Help:    "请求延迟，单位秒",
  Buckets: prometheus.LinearBuckets(0, 3, 6), // 调用LinearBuckets生成区间，从0开始，宽度3，共6个Bucket
 }, []string{"path"})

 // 注册指标
 prometheus.MustRegister(reqDelay)

 // 设置值
 reqDelay.WithLabelValues("/api").Observe(6)
 reqDelay.WithLabelValues("/user").Observe(3)
 reqDelay.WithLabelValues("/delete").Observe(2)
 reqDelay.WithLabelValues("/get_token").Observe(13)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

4. Summary指标类型

4.1 不带label的例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 reqDelay := prometheus.NewSummary(prometheus.SummaryOpts{
  Name:       "request_delay",
  Help:       "请求延迟",
  Objectives: map[float64]float64{0.5: 0.05, 0.90: 0.01, 0.99: 0.001}, // 百分比:精度
 })

 // 注册指标
 prometheus.MustRegister(reqDelay)

 // 设置值
 reqDelay.Observe(4)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

4.2 带有固定label的例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 reqDelay := prometheus.NewSummary(prometheus.SummaryOpts{
  Name:        "request_delay",
  Help:        "请求延迟",
  Objectives:  map[float64]float64{0.5: 0.05, 0.90: 0.01, 0.99: 0.001}, // 百分比:精度
  ConstLabels: prometheus.Labels{"path": "/api"},
 })

 // 注册指标
 prometheus.MustRegister(reqDelay)

 // 设置值
 reqDelay.Observe(4)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

4.3 带有非固定label的例子

package main

import (
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 // 定义指标
 reqDelay := prometheus.NewSummaryVec(prometheus.SummaryOpts{
  Name:       "request_delay",
  Help:       "请求延迟",
  Objectives: map[float64]float64{0.5: 0.05, 0.90: 0.01, 0.99: 0.001}, // 百分比:精度
 }, []string{"path"})

 // 注册指标
 prometheus.MustRegister(reqDelay)

 // 设置值
 reqDelay.WithLabelValues("/api").Observe(4)
 reqDelay.WithLabelValues("/token").Observe(2)
 reqDelay.WithLabelValues("/user").Observe(3)

 // 暴露指标
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

5. 值的修改

5.1 基于事件的触发来修改值，比如每访问1次/api就增1

基于事件的触发对指标的值进行修改，通常大多数是来自业务方面的指标需求，如自研的应用需要暴露相关指标给promethus进行监控、展示，那么指标采集的代码（指标定义、设置值）就要嵌入到自研应用代码里了。

package main

import (
 "fmt"
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
)

func main() {
 urlRequestTotal := prometheus.NewCounterVec(prometheus.CounterOpts{
  Name: "urlRequestTotal",
  Help: "PATH请求累计 单位 次",
 }, []string{"path"})

 http.HandleFunc("/api", func(w http.ResponseWriter, r *http.Request) {
  urlRequestTotal.WithLabelValues(r.URL.Path).Inc() // 使用Inc函数进行增1
  fmt.Fprintf(w, "Welcome to the api")
 })

 prometheus.MustRegister(urlRequestTotal)
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

5.2 基于时间周期的触发来修改值，比如下面的示例中，是每间隔1秒获取cpu负载指标

基于时间周期的触发，可以是多少秒、分、时、日、月、周。

package main

import (
 "net/http"
 "time"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
 "github.com/shirou/gopsutil/load"
)

func main() {

 cpuUsage := prometheus.NewGaugeVec(prometheus.GaugeOpts{
  Name: "CpuLoad",
  Help: "CPU负载",
 }, []string{"time"})

 // 开启一个子协程执行该匿名函数内的逻辑来给指标设置值，且每秒获取一次
 go func() {
  for range time.Tick(time.Second) {
   info, _ := load.Avg()
   cpuUsage.WithLabelValues("Load1").Set(float64(info.Load1))
   cpuUsage.WithLabelValues("Load5").Set(float64(info.Load5))
   cpuUsage.WithLabelValues("Load15").Set(float64(info.Load15))
  }
 }()

 prometheus.MustRegister(cpuUsage)

 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}

5.3 基于每访问一次获取指标的URI才修改值，比如每次访问/metrics才去修改某些指标的值

下面的这个示例是，每访问一次/metrics就获取一次内存总容量

package main

import (
 "fmt"
 "net/http"

 "github.com/prometheus/client_golang/prometheus"
 "github.com/prometheus/client_golang/prometheus/promhttp"
 "github.com/shirou/gopsutil/mem"
)

func main() {
 MemTotal := prometheus.NewGaugeFunc(prometheus.GaugeOpts{
  Name: "MemTotal",
  Help: "内存总容量 单位 GB",
 }, func() float64 {
  fmt.Println("call MemTotal ...")
  info, _ := mem.VirtualMemory()
  return float64(info.Total / 1024 / 1024 / 1024)
 })
 prometheus.MustRegister(MemTotal)
 http.Handle("/metrics", promhttp.Handler())
 http.ListenAndServe(":9900", nil)
}
