一、Checkmk简单介绍

Checkmk is software developed in Python and C++ for IT Infrastructure monitoring. It is used for the monitoring of servers, applications, networks, cloud infrastructures ( public, private, hybrid ), containers, storage, databases and environment sensors. Monitor your entire hybrid IT infrastructure

Checkmk是一款德国出品的开源监控软件，这款监控软件保持了德国软件的严谨、稳定、设计巧妙的特点，不得不服

二、Check服务端安装包下载与部署

wget https://download.checkmk.com/checkmk/2.1.0p18/check-mk-raw-2.1.0p18-el7-38.x86_64.rpm

yum localinstall check-mk-raw-2.1.0p18-el7-38.x86_64.rpm

omd version
omd create checkmk
omd start checkmk
firewall-cmd --permanent --zone=public --add-port=80/tcp
firewall-cmd --reload

服务端还需要开放如下端口

端口说明参考如下链接

https://docs.checkmk.com/latest/en/ports.html

firewall-cmd --permanent --zone=public --add-port=8000/tcp
firewall-cmd --permanent --zone=public --add-port=443/tcp
firewall-cmd --permanent --zone=public --add-port=514/tcp
firewall-cmd --permanent --zone=public --add-port=514/udp
firewall-cmd --permanent --zone=public --add-port=162/udp
firewall-cmd --permanent --zone=public --add-port=6559/udp
firewall-cmd --reload

check-mk服务器web界面

1、修改管理员密码

2、界面截图

三、Linux客户端安装check-mk-agent

yum install xinetd -y
wget http://192.168.31.170/checkmk/check_mk/agents/check-mk-agent-2.1.0p18-1.noarch.rpm
rpm -ivh check-mk-agent-2.1.0p18-1.noarch.rpm
firewall-cmd --permanent --zone=public --add-port=6556/tcp
firewall-cmd --reload
