完成端口与线程池的关系_端口触发

#include "stdafx.h"
#include <Afx.h>
#include <Windows.h>
#include <Winsock2.h>
#pragma comment(lib, "WS2_32.lib")
#include <mswsock.h>    //微软扩展的类库
#define DATA_BUFSIZE 100
#define READ   0
#define WRITE  1
#define ACCEPT 2
DWORD g_count = 0;
//扩展的输入输出结构
typedef struct _io_operation_data
{
OVERLAPPED	overlapped;
WSABUF		databuf;
CHAR		buffer[DATA_BUFSIZE];
BYTE		type;
DWORD		len;
SOCKET		sock;
}IO_OPERATION_DATA, *LP_IO_OPERATION_DATA;
//完成键
typedef struct _completion_key
{
SOCKET sock;
char   sIP[30];		//本机测试，IP都是127.0.0.1，没啥意思，实际写时候这个值填的是端口号
}COMPLETION_KEY, *LP_COMPLETION_KEY;
///
//完成端口句柄
HANDLE g_hComPort = NULL;
BOOL   g_bRun = FALSE;
BOOL AcceptClient(SOCKET sListen);		//发起接收连接操作
BOOL Recv(COMPLETION_KEY *pComKey, IO_OPERATION_DATA *pIO);	//发起接收操作
BOOL Send(COMPLETION_KEY *pComKey, IO_OPERATION_DATA *pIO);	//发起发送操作
//处理重叠结果
BOOL ProcessIO(IO_OPERATION_DATA *pIOdata, COMPLETION_KEY *pComKey);
//
//服务线程
DWORD WINAPI ServerWorkerThread( LPVOID pParam );
//
LPFN_ACCEPTEX lpfnAcceptEx = NULL;					 //AcceptEx函数指针
LPFN_GETACCEPTEXSOCKADDRS lpfnGetAcceptExSockaddrs;  //加载GetAcceptExSockaddrs函数指针
///
//监听套接字,其实也不一定要是全局的。用于接收到连接后继续发起等待连接操作。
SOCKET g_sListen;
int main(int argc, char* argv[])
{
g_bRun = TRUE;
//创建完成端口
g_hComPort = CreateIoCompletionPort( INVALID_HANDLE_VALUE, NULL, 0, 0 );
if( g_hComPort == NULL )
{
printf("Create completionport error!   %d\n", WSAGetLastError() );
return 0;
}
//创建服务线程
SYSTEM_INFO sysInfor;
GetSystemInfo( &sysInfor );
int i=0;
for(i = 0; i < sysInfor.dwNumberOfProcessors * 2; i++)
//	if(true)
{
HANDLE hThread;
DWORD  dwThreadID;
hThread = CreateThread( NULL, 0, ServerWorkerThread, g_hComPort, 0, &dwThreadID );
CloseHandle( hThread );
}
//加载套接字库
WSADATA wsData;
if( 0 != WSAStartup( 0x0202, &wsData ) )
{
printf("加载套接字库失败!   %d\n", WSAGetLastError() );
g_bRun = FALSE;
return 0;
}
//等待客户端连接
//先创建一个套接字用于监听
SOCKET sListen = WSASocket( AF_INET, SOCK_STREAM, 0, NULL, 0, WSA_FLAG_OVERLAPPED );
g_sListen = sListen;
//将监听套接字与完成端口绑定
LP_COMPLETION_KEY pComKey;		//完成键
pComKey = (LP_COMPLETION_KEY) GlobalAlloc ( GPTR, sizeof(COMPLETION_KEY) );
pComKey->sock = sListen;
CreateIoCompletionPort( (HANDLE)sListen, g_hComPort, (DWORD)pComKey, 0 );
//监听套接字绑定监听
SOCKADDR_IN serAdd;
serAdd.sin_addr.S_un.S_addr = htonl(INADDR_ANY);
serAdd.sin_family = AF_INET;
serAdd.sin_port = htons( 6000 );
bind( sListen, (SOCKADDR*)&serAdd, sizeof(SOCKADDR) );
listen( sListen, 5 );
if( sListen == SOCKET_ERROR )
{
goto STOP_SERVER;
}
/
//使用WSAIoctl获取AcceptEx函数指针
if( true )
{
DWORD dwbytes = 0;
//Accept function GUID
GUID guidAcceptEx = WSAID_ACCEPTEX;
if( 0 != WSAIoctl( sListen, SIO_GET_EXTENSION_FUNCTION_POINTER,
&guidAcceptEx, sizeof(guidAcceptEx),
&lpfnAcceptEx, sizeof(lpfnAcceptEx),
&dwbytes, NULL, NULL) )
{
//百度百科,有关该函数的所有返回值都有！
}
// 获取GetAcceptExSockAddrs函数指针，也是同理
GUID guidGetAcceptExSockaddrs = WSAID_GETACCEPTEXSOCKADDRS;
if( 0 != WSAIoctl( sListen, SIO_GET_EXTENSION_FUNCTION_POINTER,
&guidGetAcceptExSockaddrs,
sizeof(guidGetAcceptExSockaddrs),
&lpfnGetAcceptExSockaddrs,
sizeof(lpfnGetAcceptExSockaddrs),
&dwbytes, NULL, NULL) )
{
}
}
//发起接收的异步操作
for(i=0; i<2000; i++ )
{
AcceptClient(sListen);
}
//不让主线程退出
while( g_bRun )
{
Sleep(1000);
}
STOP_SERVER:
closesocket( sListen );
g_bRun = FALSE;
WSACleanup();
return 0;
}
/
//服务线程
DWORD WINAPI ServerWorkerThread( LPVOID pParam )
{
HANDLE  completionPort = (HANDLE)pParam;
DWORD	dwIoSize;
COMPLETION_KEY		  *pComKey;		//完成键
LP_IO_OPERATION_DATA  lpIOoperData;		//I/O数据
//用于发起接收重叠操作
BOOL bRet;
while( g_bRun )
{
bRet = FALSE;
dwIoSize = -1;
pComKey = NULL;
lpIOoperData = NULL;
bRet = GetQueuedCompletionStatus( g_hComPort, &dwIoSize, (LPDWORD)&pComKey, (LPOVERLAPPED*)&lpIOoperData,INFINITE );
if( !bRet )
{
DWORD dwIOError = GetLastError();
if( WAIT_TIMEOUT == dwIOError )
{
continue;
}
else if( NULL != lpIOoperData )
{
CancelIo( (HANDLE)pComKey->sock );	//取消等待执行的异步操作
closesocket(pComKey->sock);
GlobalFree( pComKey );
}
else
{
g_bRun = FALSE;
break;
}
}
else
{
if( 0 == dwIoSize  && (READ==lpIOoperData->type || WRITE==lpIOoperData->type) )
{
printf("客户断开了连接!\n");
CancelIo( (HANDLE)pComKey->sock );	//取消等待执行的异步操作
closesocket(pComKey->sock);
GlobalFree( pComKey );
GlobalFree( lpIOoperData );
continue;
}
else
{
ProcessIO( lpIOoperData, pComKey );
}
}
}
return 0;
}
BOOL ProcessIO(IO_OPERATION_DATA *pIOoperData, COMPLETION_KEY *pComKey)
{
if( pIOoperData->type == READ )
{
//打印接收到的内容
//	char ch[100] = { 0 };
//	sprintf(ch, "%s  :  %s", pComKey->sIP, pIOoperData->buffer);
//	printf( ch );
Send( pComKey, pIOoperData );	//将接收到的内容原封不动的发送回去
}
else if( pIOoperData->type == WRITE )
{
Recv( pComKey, pIOoperData );	//发起接收操作
}
else if( pIOoperData->type == ACCEPT )
{	//使用GetAcceptExSockaddrs函数 获得具体的各个地址参数.
printf("accept sucess!\n");
setsockopt( pIOoperData->sock, SOL_SOCKET, SO_UPDATE_ACCEPT_CONTEXT, (char*)&(pComKey->sock), sizeof(pComKey->sock) );
LP_COMPLETION_KEY pClientComKey = (LP_COMPLETION_KEY) GlobalAlloc ( GPTR, sizeof(COMPLETION_KEY) );
pClientComKey->sock = pIOoperData->sock;
SOCKADDR_IN *addrClient = NULL, *addrLocal = NULL;
int nClientLen = sizeof(SOCKADDR_IN), nLocalLen = sizeof(SOCKADDR_IN);
lpfnGetAcceptExSockaddrs(pIOoperData->buffer, 0,
sizeof(SOCKADDR_IN)+16, sizeof(SOCKADDR_IN)+16,
(LPSOCKADDR*)&addrLocal, &nLocalLen,
(LPSOCKADDR*)&addrClient, &nClientLen);
sprintf(pClientComKey->sIP, "%d", addrClient->sin_port );	//cliAdd.sin_port );
printf(pClientComKey->sIP );
CreateIoCompletionPort( (HANDLE)pClientComKey->sock, g_hComPort, (DWORD)pClientComKey, 0 );	//将监听到的套接字关联到完成端口
Recv( pClientComKey, pIOoperData );
//	char s[30] = {0};
//	sprintf( s, "%d\n", g_count++ );
//	printf(s);
//接收到一个连接，就再发起一个异步操作！
AcceptClient( g_sListen );
}
return TRUE;
}
BOOL AcceptClient(SOCKET sListen)
{
DWORD dwBytes;
LP_IO_OPERATION_DATA pIO;
pIO = (LP_IO_OPERATION_DATA) GlobalAlloc (GPTR, sizeof(IO_OPERATION_DATA));
pIO->databuf.buf = pIO->buffer;
pIO->databuf.len = pIO->len = DATA_BUFSIZE;
pIO->type = ACCEPT;
//先创建一个套接字(相比accept有点就在此,accept是接收到连接才创建出来套接字,浪费时间. 这里先准备一个,用于接收连接)
pIO->sock = WSASocket( AF_INET, SOCK_STREAM, 0, NULL, 0, WSA_FLAG_OVERLAPPED );
//调用AcceptEx函数，地址长度需要在原有的上面加上16个字节
//向服务线程投递一个接收连接的的请求
BOOL rc = lpfnAcceptEx( sListen, pIO->sock,
pIO->buffer, 0,
sizeof(SOCKADDR_IN)+16, sizeof(SOCKADDR_IN)+16,
&dwBytes, &(pIO->overlapped) );
if( FALSE == rc )
{
if( WSAGetLastError() != ERROR_IO_PENDING )
{
printf("%d", WSAGetLastError() );
return false;
}
}
return true;
}
BOOL Recv(COMPLETION_KEY *pComKey, IO_OPERATION_DATA *pIOoperData)
{
DWORD flags = 0;
DWORD recvBytes = 0;
ZeroMemory( &pIOoperData->overlapped, sizeof(OVERLAPPED) );
pIOoperData->type = READ;
pIOoperData->databuf.buf = pIOoperData->buffer;
pIOoperData->databuf.len = pIOoperData->len = DATA_BUFSIZE;
if( SOCKET_ERROR == WSARecv( pComKey->sock, &pIOoperData->databuf, 1, &recvBytes, &flags,  &pIOoperData->overlapped, NULL) )
{
if( ERROR_IO_PENDING != WSAGetLastError() )
{
printf("发起重叠接收失败!   %d\n", GetLastError() );
return FALSE;
}
}
return TRUE;
}
BOOL Send(COMPLETION_KEY *pComKey, IO_OPERATION_DATA *pIOoperData)
{
DWORD flags = 0;
DWORD recvBytes = 0;
ZeroMemory( &pIOoperData->overlapped, sizeof(OVERLAPPED) );
pIOoperData->type = WRITE;
pIOoperData->databuf.len = 100;
if( SOCKET_ERROR == WSASend( pComKey->sock, &pIOoperData->databuf, 1, &recvBytes, flags,  &pIOoperData->overlapped , NULL) )
{
if( ERROR_IO_PENDING != WSAGetLastError() )
{
printf("发起发送重叠接收失败!\n");
return FALSE;
}
}
return TRUE;
}

#include "stdafx.h"
#include <Afx.h>
#include <Windows.h>
#include <Winsock2.h>
#pragma comment(lib, "WS2_32.lib")
DWORD WINAPI Thread(LPVOID lParam);
int main(int argc, char* argv[])
{
WSADATA dwData;
WSAStartup( 0x0202, &dwData );
for( int i = 0; i < 2000; i++ )
{
HANDLE hThread = NULL;
hThread = CreateThread(NULL, 0, Thread, NULL, 0, 0);
CloseHandle(hThread);
hThread = NULL;
}
while( true )
{
Sleep(100);
}
return 0;
}
DWORD WINAPI Thread(LPVOID lParam)
{
SOCKET sock = socket( AF_INET, SOCK_STREAM, 0 );
SOCKADDR_IN serAddr;
serAddr.sin_family = AF_INET;
serAddr.sin_port = htons(6000);
serAddr.sin_addr.S_un.S_addr = inet_addr(_T("127.0.0.1"));
int reVal = connect( sock, (SOCKADDR*)&serAddr, sizeof(SOCKADDR) );
if( reVal==SOCKET_ERROR )
{
printf("cannot client SERVER!   %d\n", WSAGetLastError());
return 0;
}
int i=0;
char buf[100] = _T("光阴的故事!\n");
while( true )
{
if( SOCKET_ERROR == send( sock, buf, 100, 0 ) )
{
printf("cannot SEND message to server!   %d\n", WSAGetLastError());
break;
}
memset( buf, 0, strlen(buf) );	//清空一下，体现是接收到的数据
if(  SOCKET_ERROR == recv( sock, buf, 100, 0 ) )
{
printf("cannot RECV message to server!   %d\n", WSAGetLastError());
break;
}
//	printf( buf );
Sleep(3000);
}
closesocket(sock);
return 0;
}
