RDMA - GDR GPU Direct RDMA快速入门2

#客户端:
root@gdr114:~/project/rdma/perftest# ./ib_write_bw -d mlx5_0 --use_cuda=0 192.168.1.116
Perftest doesn't supports CUDA tests with inline messages: inline size set to 0
initializing CUDA
Listing all CUDA devices in system:
CUDA device 0: PCIe address is 05:00
​
Picking device No. 0
[pid = 4800, dev = 0] device name = [Tesla V100-SXM2-16GB]
creating CUDA Ctx
making it the current CUDA Ctx
CUDA device integrated: 0
cuMemAlloc() of a 131072 bytes GPU buffer
allocated GPU buffer address at 00007c8f3da00000 pointer=0x7c8f3da00000
---------------------------------------------------------------------------------------
                    RDMA_Write BW Test
 Dual-port       : OFF      Device         : mlx5_0
 Number of qps   : 1        Transport type : IB
 Connection type : RC       Using SRQ      : OFF
 PCIe relax order: ON       Lock-free      : OFF
 WARNING: CPU is not PCIe relaxed ordering compliant.
 WARNING: You should disable PCIe RO with `--disable_pcie_relaxed` for both server and client.
 ibv_wr* API     : ON       Using DDP      : OFF
 TX depth        : 128
 CQ Moderation   : 1
 Mtu             : 1024[B]
 Link type       : Ethernet
 GID index       : 3
 Max inline data : 0[B]
 rdma_cm QPs     : OFF
 Data ex. method : Ethernet
---------------------------------------------------------------------------------------
 local address: LID 0000 QPN 0x01c9 PSN 0xa7f08e RKey 0x1fccbc VAddr 0x007c8f3da10000
 GID: 00:00:00:00:00:00:00:00:00:00:255:255:192:168:01:114
 remote address: LID 0000 QPN 0x01c9 PSN 0x682a07 RKey 0x1fccbc VAddr 0x007851b5a10000
 GID: 00:00:00:00:00:00:00:00:00:00:255:255:192:168:01:116
---------------------------------------------------------------------------------------
 #bytes     #iterations    BW peak[MiB/sec]    BW average[MiB/sec]   MsgRate[Mpps]
Conflicting CPU frequency values detected: 1200.907000 != 2100.000000. CPU Frequency is not max.
 65536      5000             2471.09            2452.52          0.039240
---------------------------------------------------------------------------------------
deallocating GPU buffer 00007c8f3da00000
destroying current CUDA Ctx
​
#服务端:
root@gdr116:~/project/rdma/perftest# ./ib_write_bw -d mlx5_0 --use_cuda=0
Perftest doesn't supports CUDA tests with inline messages: inline size set to 0
​
************************************
* Waiting for client to connect... *
************************************
initializing CUDA
Listing all CUDA devices in system:
CUDA device 0: PCIe address is 04:00
​
Picking device No. 0
[pid = 5561, dev = 0] device name = [Tesla V100-SXM2-16GB]
creating CUDA Ctx
making it the current CUDA Ctx
CUDA device integrated: 0
cuMemAlloc() of a 131072 bytes GPU buffer
allocated GPU buffer address at 00007851b5a00000 pointer=0x7851b5a00000
---------------------------------------------------------------------------------------
                    RDMA_Write BW Test
 Dual-port       : OFF      Device         : mlx5_0
 Number of qps   : 1        Transport type : IB
 Connection type : RC       Using SRQ      : OFF
 PCIe relax order: ON       Lock-free      : OFF
 WARNING: CPU is not PCIe relaxed ordering compliant.
 WARNING: You should disable PCIe RO with `--disable_pcie_relaxed` for both server and client.
 ibv_wr* API     : ON       Using DDP      : OFF
 CQ Moderation   : 1
 Mtu             : 1024[B]
 Link type       : Ethernet
 GID index       : 3
 Max inline data : 0[B]
 rdma_cm QPs     : OFF
 Data ex. method : Ethernet
---------------------------------------------------------------------------------------
 local address: LID 0000 QPN 0x01c9 PSN 0x682a07 RKey 0x1fccbc VAddr 0x007851b5a10000
 GID: 00:00:00:00:00:00:00:00:00:00:255:255:192:168:01:116
 remote address: LID 0000 QPN 0x01c9 PSN 0xa7f08e RKey 0x1fccbc VAddr 0x007c8f3da10000
 GID: 00:00:00:00:00:00:00:00:00:00:255:255:192:168:01:114
---------------------------------------------------------------------------------------
 #bytes     #iterations    BW peak[MiB/sec]    BW average[MiB/sec]   MsgRate[Mpps]
 65536      5000             2471.09            2452.52          0.039240
---------------------------------------------------------------------------------------
deallocating GPU buffer 00007851b5a00000
destroying current CUDA Ctx

客户端:
root@gdr114:~/project/rdma/perftest# ./ib_write_bw -d mlx5_0 --use_cuda=0 --use_cuda_dmabuf 192.168.1.116
Perftest doesn't supports CUDA tests with inline messages: inline size set to 0
initializing CUDA
Listing all CUDA devices in system:
CUDA device 0: PCIe address is 05:00
​
Picking device No. 0
[pid = 3573, dev = 0] device name = [NVIDIA RTX A6000]
creating CUDA Ctx
making it the current CUDA Ctx
CUDA device integrated: 0
cuMemAlloc() of a 131072 bytes GPU buffer
allocated GPU buffer address at 00007c7d90600000 pointer=0x7c7d90600000
using DMA-BUF for GPU buffer address at 0x7c7d90600000 aligned at 0x7c7d90600000 with aligned size 131072
Calling ibv_reg_dmabuf_mr(offset=0, size=131072, addr=0x7c7d90600000, fd=37) for QP #0
---------------------------------------------------------------------------------------
                    RDMA_Write BW Test
 Dual-port       : OFF      Device         : mlx5_0
 Number of qps   : 1        Transport type : IB
 Connection type : RC       Using SRQ      : OFF
 PCIe relax order: ON       Lock-free      : OFF
 WARNING: CPU is not PCIe relaxed ordering compliant.
 WARNING: You should disable PCIe RO with `--disable_pcie_relaxed` for both server and client.
 ibv_wr* API     : ON       Using DDP      : OFF
 TX depth        : 128
 CQ Moderation   : 1
 Mtu             : 1024[B]
 Link type       : Ethernet
 GID index       : 3
 Max inline data : 0[B]
 rdma_cm QPs     : OFF
 Data ex. method : Ethernet
---------------------------------------------------------------------------------------
 local address: LID 0000 QPN 0x01ca PSN 0x76adeb RKey 0x176d5d VAddr 0x007c7d90610000
 GID: 00:00:00:00:00:00:00:00:00:00:255:255:192:168:01:114
 remote address: LID 0000 QPN 0x01ca PSN 0xe79753 RKey 0x176f5f VAddr 0x00792a04610000
 GID: 00:00:00:00:00:00:00:00:00:00:255:255:192:168:01:116
---------------------------------------------------------------------------------------
 #bytes     #iterations    BW peak[MiB/sec]    BW average[MiB/sec]   MsgRate[Mpps]
Conflicting CPU frequency values detected: 1200.966000 != 3299.943000. CPU Frequency is not max.
 65536      5000             2758.05            2758.04          0.044129
---------------------------------------------------------------------------------------
deallocating GPU buffer 00007c7d90600000
destroying current CUDA Ctx
​
​
服务端:
root@gdr116:~/project/rdma/perftest# ./ib_write_bw -d mlx5_0 --use_cuda=0 --use_cuda_dmabuf
Perftest doesn't supports CUDA tests with inline messages: inline size set to 0
​
************************************
* Waiting for client to connect... *
************************************
initializing CUDA
Listing all CUDA devices in system:
CUDA device 0: PCIe address is 04:00
​
Picking device No. 0
[pid = 4694, dev = 0] device name = [NVIDIA RTX A6000]
creating CUDA Ctx
making it the current CUDA Ctx
CUDA device integrated: 0
cuMemAlloc() of a 131072 bytes GPU buffer
allocated GPU buffer address at 0000792a04600000 pointer=0x792a04600000
using DMA-BUF for GPU buffer address at 0x792a04600000 aligned at 0x792a04600000 with aligned size 131072
Calling ibv_reg_dmabuf_mr(offset=0, size=131072, addr=0x792a04600000, fd=37) for QP #0
---------------------------------------------------------------------------------------
                    RDMA_Write BW Test
 Dual-port       : OFF      Device         : mlx5_0
 Number of qps   : 1        Transport type : IB
 Connection type : RC       Using SRQ      : OFF
 PCIe relax order: ON       Lock-free      : OFF
 WARNING: CPU is not PCIe relaxed ordering compliant.
 WARNING: You should disable PCIe RO with `--disable_pcie_relaxed` for both server and client.
 ibv_wr* API     : ON       Using DDP      : OFF
 CQ Moderation   : 1
 Mtu             : 1024[B]
 Link type       : Ethernet
 GID index       : 3
 Max inline data : 0[B]
 rdma_cm QPs     : OFF
 Data ex. method : Ethernet
---------------------------------------------------------------------------------------
 local address: LID 0000 QPN 0x01ca PSN 0xe79753 RKey 0x176f5f VAddr 0x00792a04610000
 GID: 00:00:00:00:00:00:00:00:00:00:255:255:192:168:01:116
 remote address: LID 0000 QPN 0x01ca PSN 0x76adeb RKey 0x176d5d VAddr 0x007c7d90610000
 GID: 00:00:00:00:00:00:00:00:00:00:255:255:192:168:01:114
---------------------------------------------------------------------------------------
 #bytes     #iterations    BW peak[MiB/sec]    BW average[MiB/sec]   MsgRate[Mpps]
 65536      5000             2758.05            2758.04          0.044129
---------------------------------------------------------------------------------------
deallocating GPU buffer 0000792a04600000
destroying current CUDA Ctx

客户端:
ib_write_bw -d mlx5_0 --use_cuda=0 192.168.1.116

cuda_memory_init(struct memory_ctx * ctx) (\root\project\rdma\perftest\src\cuda_memory.c:111)
ctx_init(struct pingpong_context * ctx, struct pingpong_context * ctx@entry, struct perftest_parameters * user_param, struct perftest_parameters * user_param@entry) (\root\project\rdma\perftest\src\perftest_resources.c:2089)
main(int argc, char ** argv) (\root\project\rdma\perftest\src\write_bw.c:161)
​
...
cuda_memory_init
    return_value = init_gpu(cuda_ctx)
        CUresult error = cuInit(0)
        error = cuCtxCreate(&ctx->cuContext, CU_CTX_MAP_HOST, ctx->cuDevice)
        error = cuCtxSetCurrent(ctx->cuContext)
​

分配和注册内存:
ibv_reg_mr
cuda_memory_allocate_buffer(struct memory_ctx * ctx, int alignment, uint64_t size, int * dmabuf_fd, uint64_t * dmabuf_offset, void ** addr, _Bool * can_init) (\root\project\rdma\perftest\src\cuda_memory.c:194)
create_single_mr(struct pingpong_context * ctx, struct pingpong_context * ctx@entry, struct perftest_parameters * user_param, struct perftest_parameters * user_param@entry, int qp_index, int qp_index@entry) (\root\project\rdma\perftest\src\perftest_resources.c:1661)
create_mr(struct pingpong_context * ctx, struct pingpong_context * ctx@entry, struct perftest_parameters * user_param, struct perftest_parameters * user_param@entry) (\root\project\rdma\perftest\src\perftest_resources.c:1858)
ctx_init(struct pingpong_context * ctx, struct pingpong_context * ctx@entry, struct perftest_parameters * user_param, struct perftest_parameters * user_param@entry) (\root\project\rdma\perftest\src\perftest_resources.c:2094)
main(int argc, char ** argv) (\root\project\rdma\perftest\src\write_bw.c:161)

root@gdr116:~/project/rdma/perftest# ./ib_write_bw -d mlx5_0 --use_cuda=0 --use_cuda_dmabuf
Perftest doesn't supports CUDA tests with inline messages: inline size set to 0
​
************************************
* Waiting for client to connect... *
************************************
initializing CUDA
Listing all CUDA devices in system:
CUDA device 0: PCIe address is 04:00
​
Picking device No. 0
[pid = 54519, dev = 0] device name = [Tesla V100-SXM2-16GB]
creating CUDA Ctx
making it the current CUDA Ctx
DMA-BUF is not supported on this GPU // 该GPU不支持DMA_BUF
Failed to init memory
 Couldn't create IB resources
destroying current CUDA Ctx
​
检测GPU是否支持DMA_BUF的代码:
#ifdef HAVE_CUDA_DMABUF
    if (cuda_ctx->use_dmabuf) {
        int is_supported = 0;
​
        CUCHECK(cuDeviceGetAttribute(&is_supported, CU_DEVICE_ATTRIBUTE_DMA_BUF_SUPPORTED, cuda_ctx->cuDevice));
        if (!is_supported) {
            fprintf(stderr, "DMA-BUF is not supported on this GPU\n");
            return FAILURE;
        }
    }
#endif

/**
 * Device properties
 */
typedef enum CUdevice_attribute_enum {
    CU_DEVICE_ATTRIBUTE_MAX_THREADS_PER_BLOCK = 1,                          /**< Maximum number of threads per block */
    CU_DEVICE_ATTRIBUTE_MAX_BLOCK_DIM_X = 2,                                /**< Maximum block dimension X */
    CU_DEVICE_ATTRIBUTE_MAX_BLOCK_DIM_Y = 3,                                /**< Maximum block dimension Y */
    CU_DEVICE_ATTRIBUTE_MAX_BLOCK_DIM_Z = 4,                                /**< Maximum block dimension Z */
    CU_DEVICE_ATTRIBUTE_MAX_GRID_DIM_X = 5,                                 /**< Maximum grid dimension X */
    CU_DEVICE_ATTRIBUTE_MAX_GRID_DIM_Y = 6,                                 /**< Maximum grid dimension Y */
    CU_DEVICE_ATTRIBUTE_MAX_GRID_DIM_Z = 7,                                 /**< Maximum grid dimension Z */
    CU_DEVICE_ATTRIBUTE_MAX_SHARED_MEMORY_PER_BLOCK = 8,                    /**< Maximum shared memory available per block in bytes */
    CU_DEVICE_ATTRIBUTE_SHARED_MEMORY_PER_BLOCK = 8,                        /**< Deprecated, use CU_DEVICE_ATTRIBUTE_MAX_SHARED_MEMORY_PER_BLOCK */
    CU_DEVICE_ATTRIBUTE_TOTAL_CONSTANT_MEMORY = 9,                          /**< Memory available on device for __constant__ variables in a CUDA C kernel in bytes */
    CU_DEVICE_ATTRIBUTE_WARP_SIZE = 10,                                     /**< Warp size in threads */
    CU_DEVICE_ATTRIBUTE_MAX_PITCH = 11,                                     /**< Maximum pitch in bytes allowed by memory copies */
    CU_DEVICE_ATTRIBUTE_MAX_REGISTERS_PER_BLOCK = 12,                       /**< Maximum number of 32-bit registers available per block */
    CU_DEVICE_ATTRIBUTE_REGISTERS_PER_BLOCK = 12,                           /**< Deprecated, use CU_DEVICE_ATTRIBUTE_MAX_REGISTERS_PER_BLOCK */
    CU_DEVICE_ATTRIBUTE_CLOCK_RATE = 13,                                    /**< Typical clock frequency in kilohertz */
    CU_DEVICE_ATTRIBUTE_TEXTURE_ALIGNMENT = 14,                             /**< Alignment requirement for textures */
    CU_DEVICE_ATTRIBUTE_GPU_OVERLAP = 15,                                   /**< Device can possibly copy memory and execute a kernel concurrently. Deprecated. Use instead CU_DEVICE_ATTRIBUTE_ASYNC_ENGINE_COUNT. */
    CU_DEVICE_ATTRIBUTE_MULTIPROCESSOR_COUNT = 16,                          /**< Number of multiprocessors on device */
    CU_DEVICE_ATTRIBUTE_KERNEL_EXEC_TIMEOUT = 17,                           /**< Specifies whether there is a run time limit on kernels */
    CU_DEVICE_ATTRIBUTE_INTEGRATED = 18,                                    /**< Device is integrated with host memory */
    CU_DEVICE_ATTRIBUTE_CAN_MAP_HOST_MEMORY = 19,                           /**< Device can map host memory into CUDA address space */
    CU_DEVICE_ATTRIBUTE_COMPUTE_MODE = 20,                                  /**< Compute mode (See ::CUcomputemode for details) */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE1D_WIDTH = 21,                       /**< Maximum 1D texture width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_WIDTH = 22,                       /**< Maximum 2D texture width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_HEIGHT = 23,                      /**< Maximum 2D texture height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE3D_WIDTH = 24,                       /**< Maximum 3D texture width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE3D_HEIGHT = 25,                      /**< Maximum 3D texture height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE3D_DEPTH = 26,                       /**< Maximum 3D texture depth */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_LAYERED_WIDTH = 27,               /**< Maximum 2D layered texture width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_LAYERED_HEIGHT = 28,              /**< Maximum 2D layered texture height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_LAYERED_LAYERS = 29,              /**< Maximum layers in a 2D layered texture */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_ARRAY_WIDTH = 27,                 /**< Deprecated, use CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_LAYERED_WIDTH */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_ARRAY_HEIGHT = 28,                /**< Deprecated, use CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_LAYERED_HEIGHT */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_ARRAY_NUMSLICES = 29,             /**< Deprecated, use CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_LAYERED_LAYERS */
    CU_DEVICE_ATTRIBUTE_SURFACE_ALIGNMENT = 30,                             /**< Alignment requirement for surfaces */
    CU_DEVICE_ATTRIBUTE_CONCURRENT_KERNELS = 31,                            /**< Device can possibly execute multiple kernels concurrently */
    CU_DEVICE_ATTRIBUTE_ECC_ENABLED = 32,                                   /**< Device has ECC support enabled */
    CU_DEVICE_ATTRIBUTE_PCI_BUS_ID = 33,                                    /**< PCI bus ID of the device */
    CU_DEVICE_ATTRIBUTE_PCI_DEVICE_ID = 34,                                 /**< PCI device ID of the device */
    CU_DEVICE_ATTRIBUTE_TCC_DRIVER = 35,                                    /**< Device is using TCC driver model */
    CU_DEVICE_ATTRIBUTE_MEMORY_CLOCK_RATE = 36,                             /**< Peak memory clock frequency in kilohertz */
    CU_DEVICE_ATTRIBUTE_GLOBAL_MEMORY_BUS_WIDTH = 37,                       /**< Global memory bus width in bits */
    CU_DEVICE_ATTRIBUTE_L2_CACHE_SIZE = 38,                                 /**< Size of L2 cache in bytes */
    CU_DEVICE_ATTRIBUTE_MAX_THREADS_PER_MULTIPROCESSOR = 39,                /**< Maximum resident threads per multiprocessor */
    CU_DEVICE_ATTRIBUTE_ASYNC_ENGINE_COUNT = 40,                            /**< Number of asynchronous engines */
    CU_DEVICE_ATTRIBUTE_UNIFIED_ADDRESSING = 41,                            /**< Device shares a unified address space with the host */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE1D_LAYERED_WIDTH = 42,               /**< Maximum 1D layered texture width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE1D_LAYERED_LAYERS = 43,              /**< Maximum layers in a 1D layered texture */
    CU_DEVICE_ATTRIBUTE_CAN_TEX2D_GATHER = 44,                              /**< Deprecated, do not use. */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_GATHER_WIDTH = 45,                /**< Maximum 2D texture width if CUDA_ARRAY3D_TEXTURE_GATHER is set */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_GATHER_HEIGHT = 46,               /**< Maximum 2D texture height if CUDA_ARRAY3D_TEXTURE_GATHER is set */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE3D_WIDTH_ALTERNATE = 47,             /**< Alternate maximum 3D texture width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE3D_HEIGHT_ALTERNATE = 48,            /**< Alternate maximum 3D texture height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE3D_DEPTH_ALTERNATE = 49,             /**< Alternate maximum 3D texture depth */
    CU_DEVICE_ATTRIBUTE_PCI_DOMAIN_ID = 50,                                 /**< PCI domain ID of the device */
    CU_DEVICE_ATTRIBUTE_TEXTURE_PITCH_ALIGNMENT = 51,                       /**< Pitch alignment requirement for textures */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURECUBEMAP_WIDTH = 52,                  /**< Maximum cubemap texture width/height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURECUBEMAP_LAYERED_WIDTH = 53,          /**< Maximum cubemap layered texture width/height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURECUBEMAP_LAYERED_LAYERS = 54,         /**< Maximum layers in a cubemap layered texture */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE1D_WIDTH = 55,                       /**< Maximum 1D surface width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE2D_WIDTH = 56,                       /**< Maximum 2D surface width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE2D_HEIGHT = 57,                      /**< Maximum 2D surface height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE3D_WIDTH = 58,                       /**< Maximum 3D surface width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE3D_HEIGHT = 59,                      /**< Maximum 3D surface height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE3D_DEPTH = 60,                       /**< Maximum 3D surface depth */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE1D_LAYERED_WIDTH = 61,               /**< Maximum 1D layered surface width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE1D_LAYERED_LAYERS = 62,              /**< Maximum layers in a 1D layered surface */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE2D_LAYERED_WIDTH = 63,               /**< Maximum 2D layered surface width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE2D_LAYERED_HEIGHT = 64,              /**< Maximum 2D layered surface height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACE2D_LAYERED_LAYERS = 65,              /**< Maximum layers in a 2D layered surface */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACECUBEMAP_WIDTH = 66,                  /**< Maximum cubemap surface width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACECUBEMAP_LAYERED_WIDTH = 67,          /**< Maximum cubemap layered surface width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_SURFACECUBEMAP_LAYERED_LAYERS = 68,         /**< Maximum layers in a cubemap layered surface */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE1D_LINEAR_WIDTH = 69,                /**< Deprecated, do not use. Use cudaDeviceGetTexture1DLinearMaxWidth() or cuDeviceGetTexture1DLinearMaxWidth() instead. */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_LINEAR_WIDTH = 70,                /**< Maximum 2D linear texture width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_LINEAR_HEIGHT = 71,               /**< Maximum 2D linear texture height */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_LINEAR_PITCH = 72,                /**< Maximum 2D linear texture pitch in bytes */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_MIPMAPPED_WIDTH = 73,             /**< Maximum mipmapped 2D texture width */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE2D_MIPMAPPED_HEIGHT = 74,            /**< Maximum mipmapped 2D texture height */
    CU_DEVICE_ATTRIBUTE_COMPUTE_CAPABILITY_MAJOR = 75,                      /**< Major compute capability version number */
    CU_DEVICE_ATTRIBUTE_COMPUTE_CAPABILITY_MINOR = 76,                      /**< Minor compute capability version number */
    CU_DEVICE_ATTRIBUTE_MAXIMUM_TEXTURE1D_MIPMAPPED_WIDTH = 77,             /**< Maximum mipmapped 1D texture width */
    CU_DEVICE_ATTRIBUTE_STREAM_PRIORITIES_SUPPORTED = 78,                   /**< Device supports stream priorities */
    CU_DEVICE_ATTRIBUTE_GLOBAL_L1_CACHE_SUPPORTED = 79,                     /**< Device supports caching globals in L1 */
    CU_DEVICE_ATTRIBUTE_LOCAL_L1_CACHE_SUPPORTED = 80,                      /**< Device supports caching locals in L1 */
    CU_DEVICE_ATTRIBUTE_MAX_SHARED_MEMORY_PER_MULTIPROCESSOR = 81,          /**< Maximum shared memory available per multiprocessor in bytes */
    CU_DEVICE_ATTRIBUTE_MAX_REGISTERS_PER_MULTIPROCESSOR = 82,              /**< Maximum number of 32-bit registers available per multiprocessor */
    CU_DEVICE_ATTRIBUTE_MANAGED_MEMORY = 83,                                /**< Device can allocate managed memory on this system */
    CU_DEVICE_ATTRIBUTE_MULTI_GPU_BOARD = 84,                               /**< Device is on a multi-GPU board */
    CU_DEVICE_ATTRIBUTE_MULTI_GPU_BOARD_GROUP_ID = 85,                      /**< Unique id for a group of devices on the same multi-GPU board */
    CU_DEVICE_ATTRIBUTE_HOST_NATIVE_ATOMIC_SUPPORTED = 86,                  /**< Link between the device and the host supports native atomic operations (this is a placeholder attribute, and is not supported on any current hardware)*/
    CU_DEVICE_ATTRIBUTE_SINGLE_TO_DOUBLE_PRECISION_PERF_RATIO = 87,         /**< Ratio of single precision performance (in floating-point operations per second) to double precision performance */
    CU_DEVICE_ATTRIBUTE_PAGEABLE_MEMORY_ACCESS = 88,                        /**< Device supports coherently accessing pageable memory without calling cudaHostRegister on it */
    CU_DEVICE_ATTRIBUTE_CONCURRENT_MANAGED_ACCESS = 89,                     /**< Device can coherently access managed memory concurrently with the CPU */
    CU_DEVICE_ATTRIBUTE_COMPUTE_PREEMPTION_SUPPORTED = 90,                  /**< Device supports compute preemption. */
    CU_DEVICE_ATTRIBUTE_CAN_USE_HOST_POINTER_FOR_REGISTERED_MEM = 91,       /**< Device can access host registered memory at the same virtual address as the CPU */
    CU_DEVICE_ATTRIBUTE_CAN_USE_STREAM_MEM_OPS_V1 = 92,                     /**< Deprecated, along with v1 MemOps API, ::cuStreamBatchMemOp and related APIs are supported. */
    CU_DEVICE_ATTRIBUTE_CAN_USE_64_BIT_STREAM_MEM_OPS_V1 = 93,              /**< Deprecated, along with v1 MemOps API, 64-bit operations are supported in ::cuStreamBatchMemOp and related APIs. */
    CU_DEVICE_ATTRIBUTE_CAN_USE_STREAM_WAIT_VALUE_NOR_V1 = 94,              /**< Deprecated, along with v1 MemOps API, ::CU_STREAM_WAIT_VALUE_NOR is supported. */
    CU_DEVICE_ATTRIBUTE_COOPERATIVE_LAUNCH = 95,                            /**< Device supports launching cooperative kernels via ::cuLaunchCooperativeKernel */
    CU_DEVICE_ATTRIBUTE_COOPERATIVE_MULTI_DEVICE_LAUNCH = 96,               /**< Deprecated, ::cuLaunchCooperativeKernelMultiDevice is deprecated. */
    CU_DEVICE_ATTRIBUTE_MAX_SHARED_MEMORY_PER_BLOCK_OPTIN = 97,             /**< Maximum optin shared memory per block */
    CU_DEVICE_ATTRIBUTE_CAN_FLUSH_REMOTE_WRITES = 98,                       /**< The ::CU_STREAM_WAIT_VALUE_FLUSH flag and the ::CU_STREAM_MEM_OP_FLUSH_REMOTE_WRITES MemOp are supported on the device. See \ref CUDA_MEMOP for additional details. */
    CU_DEVICE_ATTRIBUTE_HOST_REGISTER_SUPPORTED = 99,                       /**< Device supports host memory registration via ::cudaHostRegister. */
    CU_DEVICE_ATTRIBUTE_PAGEABLE_MEMORY_ACCESS_USES_HOST_PAGE_TABLES = 100, /**< Device accesses pageable memory via the host's page tables. */
    CU_DEVICE_ATTRIBUTE_DIRECT_MANAGED_MEM_ACCESS_FROM_HOST = 101,          /**< The host can directly access managed memory on the device without migration. */
    CU_DEVICE_ATTRIBUTE_VIRTUAL_ADDRESS_MANAGEMENT_SUPPORTED = 102,         /**< Deprecated, Use CU_DEVICE_ATTRIBUTE_VIRTUAL_MEMORY_MANAGEMENT_SUPPORTED*/
    CU_DEVICE_ATTRIBUTE_VIRTUAL_MEMORY_MANAGEMENT_SUPPORTED = 102,         /**< Device supports virtual memory management APIs like ::cuMemAddressReserve, ::cuMemCreate, ::cuMemMap and related APIs */
    CU_DEVICE_ATTRIBUTE_HANDLE_TYPE_POSIX_FILE_DESCRIPTOR_SUPPORTED = 103,  /**< Device supports exporting memory to a posix file descriptor with ::cuMemExportToShareableHandle, if requested via ::cuMemCreate */
    CU_DEVICE_ATTRIBUTE_HANDLE_TYPE_WIN32_HANDLE_SUPPORTED = 104,           /**< Device supports exporting memory to a Win32 NT handle with ::cuMemExportToShareableHandle, if requested via ::cuMemCreate */
    CU_DEVICE_ATTRIBUTE_HANDLE_TYPE_WIN32_KMT_HANDLE_SUPPORTED = 105,       /**< Device supports exporting memory to a Win32 KMT handle with ::cuMemExportToShareableHandle, if requested via ::cuMemCreate */
    CU_DEVICE_ATTRIBUTE_MAX_BLOCKS_PER_MULTIPROCESSOR = 106,                /**< Maximum number of blocks per multiprocessor */
    CU_DEVICE_ATTRIBUTE_GENERIC_COMPRESSION_SUPPORTED = 107,                /**< Device supports compression of memory */
    CU_DEVICE_ATTRIBUTE_MAX_PERSISTING_L2_CACHE_SIZE = 108,                 /**< Maximum L2 persisting lines capacity setting in bytes. */
    CU_DEVICE_ATTRIBUTE_MAX_ACCESS_POLICY_WINDOW_SIZE = 109,                /**< Maximum value of CUaccessPolicyWindow::num_bytes. */
    CU_DEVICE_ATTRIBUTE_GPU_DIRECT_RDMA_WITH_CUDA_VMM_SUPPORTED = 110,      /**< Device supports specifying the GPUDirect RDMA flag with ::cuMemCreate */
    CU_DEVICE_ATTRIBUTE_RESERVED_SHARED_MEMORY_PER_BLOCK = 111,             /**< Shared memory reserved by CUDA driver per block in bytes */
    CU_DEVICE_ATTRIBUTE_SPARSE_CUDA_ARRAY_SUPPORTED = 112,                  /**< Device supports sparse CUDA arrays and sparse CUDA mipmapped arrays */
    CU_DEVICE_ATTRIBUTE_READ_ONLY_HOST_REGISTER_SUPPORTED = 113,            /**< Device supports using the ::cuMemHostRegister flag ::CU_MEMHOSTERGISTER_READ_ONLY to register memory that must be mapped as read-only to the GPU */
    CU_DEVICE_ATTRIBUTE_TIMELINE_SEMAPHORE_INTEROP_SUPPORTED = 114,         /**< External timeline semaphore interop is supported on the device */
    CU_DEVICE_ATTRIBUTE_MEMORY_POOLS_SUPPORTED = 115,                       /**< Device supports using the ::cuMemAllocAsync and ::cuMemPool family of APIs */
    CU_DEVICE_ATTRIBUTE_GPU_DIRECT_RDMA_SUPPORTED = 116,                    /**< Device supports GPUDirect RDMA APIs, like nvidia_p2p_get_pages (see https://docs.nvidia.com/cuda/gpudirect-rdma for more information) */
    CU_DEVICE_ATTRIBUTE_GPU_DIRECT_RDMA_FLUSH_WRITES_OPTIONS = 117,         /**< The returned attribute shall be interpreted as a bitmask, where the individual bits are described by the ::CUflushGPUDirectRDMAWritesOptions enum */
    CU_DEVICE_ATTRIBUTE_GPU_DIRECT_RDMA_WRITES_ORDERING = 118,              /**< GPUDirect RDMA writes to the device do not need to be flushed for consumers within the scope indicated by the returned attribute. See ::CUGPUDirectRDMAWritesOrdering for the numerical values returned here. */
    CU_DEVICE_ATTRIBUTE_MEMPOOL_SUPPORTED_HANDLE_TYPES = 119,               /**< Handle types supported with mempool based IPC */
    CU_DEVICE_ATTRIBUTE_CLUSTER_LAUNCH = 120,                               /**< Indicates device supports cluster launch */
    CU_DEVICE_ATTRIBUTE_DEFERRED_MAPPING_CUDA_ARRAY_SUPPORTED = 121,        /**< Device supports deferred mapping CUDA arrays and CUDA mipmapped arrays */
    CU_DEVICE_ATTRIBUTE_CAN_USE_64_BIT_STREAM_MEM_OPS = 122,                /**< 64-bit operations are supported in ::cuStreamBatchMemOp and related MemOp APIs. */
    CU_DEVICE_ATTRIBUTE_CAN_USE_STREAM_WAIT_VALUE_NOR = 123,                /**< ::CU_STREAM_WAIT_VALUE_NOR is supported by MemOp APIs. */
    CU_DEVICE_ATTRIBUTE_DMA_BUF_SUPPORTED = 124,                            /**< Device supports buffer sharing with dma_buf mechanism. 查看GPU是否支持DMA_BUF */
    CU_DEVICE_ATTRIBUTE_IPC_EVENT_SUPPORTED = 125,                          /**< Device supports IPC Events. */
    CU_DEVICE_ATTRIBUTE_MEM_SYNC_DOMAIN_COUNT = 126,                        /**< Number of memory domains the device supports. */
    CU_DEVICE_ATTRIBUTE_TENSOR_MAP_ACCESS_SUPPORTED = 127,                  /**< Device supports accessing memory using Tensor Map. */
    CU_DEVICE_ATTRIBUTE_UNIFIED_FUNCTION_POINTERS = 129,                    /**< Device supports unified function pointers. */
    CU_DEVICE_ATTRIBUTE_MAX
} CUdevice_attribute;
​

numactl --cpunodebind=0 --localalloc
numactl --cpunodebind=<node_list> <command>

2025/03/11 19:22:44 s114 nvidia-smi topo -m
    GPU0    NIC0    NIC1    CPU Affinity    NUMA Affinity   GPU NUMA ID
GPU0     X  PHB PHB 0-13,28-41  0       N/A
NIC0    PHB  X  PIX
NIC1    PHB PIX  X
​
Legend:
​
  X    = Self
  SYS  = Connection traversing PCIe as well as the SMP interconnect between NUMA nodes (e.g., QPI/UPI)
  NODE = Connection traversing PCIe as well as the interconnect between PCIe Host Bridges within a NUMA node
  PHB  = Connection traversing PCIe as well as a PCIe Host Bridge (typically the CPU)
  PXB  = Connection traversing multiple PCIe bridges (without traversing the PCIe Host Bridge)
  PIX  = Connection traversing at most a single PCIe bridge
  NV#  = Connection traversing a bonded set of # NVLinks
​
NIC Legend:
​
  NIC0: mlx5_0
  NIC1: mlx5_1
​
​
2025/03/11 19:22:44 s116 nvidia-smi topo -m
    GPU0    NIC0    NIC1    CPU Affinity    NUMA Affinity   GPU NUMA ID
GPU0     X  PIX PIX 0-13,28-41  0       N/A
NIC0    PIX  X  PIX
NIC1    PIX PIX  X
​
Legend:
​
  X    = Self
  SYS  = Connection traversing PCIe as well as the SMP interconnect between NUMA nodes (e.g., QPI/UPI)
  NODE = Connection traversing PCIe as well as the interconnect between PCIe Host Bridges within a NUMA node
  PHB  = Connection traversing PCIe as well as a PCIe Host Bridge (typically the CPU)
  PXB  = Connection traversing multiple PCIe bridges (without traversing the PCIe Host Bridge)
  PIX  = Connection traversing at most a single PCIe bridge
  NV#  = Connection traversing a bonded set of # NVLinks
​
NIC Legend:
​
  NIC0: mlx5_0
  NIC1: mlx5_1
​
​
lstopo-no-graphics

nvidia-smi -i 0 -ac 3004,875

#define EFAULT      14  /* Bad address */

libmlx5.so.1!mlx5_reg_mr(struct ibv_pd * pd, void * addr, size_t length, uint64_t hca_va, int acc) (\root\project\rdma\rdma-core\providers\mlx5\verbs.c:646)
libibverbs.so.1!ibv_reg_mr_iova2(struct ibv_pd * pd, void * addr, size_t length, uint64_t iova, unsigned int access) (\root\project\rdma\rdma-core\libibverbs\verbs.c:323)
__ibv_reg_mr(int is_access_const, unsigned int access) (\usr\include\infiniband\verbs.h:2591)
create_single_mr(struct pingpong_context * ctx, struct pingpong_context * ctx@entry, struct perftest_parameters * user_param, struct perftest_parameters * user_param@entry, int qp_index, int qp_index@entry) (\root\project\rdma\perftest\src\perftest_resources.c:1722)
create_mr(struct pingpong_context * ctx, struct pingpong_context * ctx@entry, struct perftest_parameters * user_param, struct perftest_parameters * user_param@entry) (\root\project\rdma\perftest\src\perftest_resources.c:1858)
ctx_init(struct pingpong_context * ctx, struct pingpong_context * ctx@entry, struct perftest_parameters * user_param, struct perftest_parameters * user_param@entry) (\root\project\rdma\perftest\src\perftest_resources.c:2094)
main(int argc, char ** argv) (\root\project\rdma\perftest\src\write_bw.c:161)

Support for 4k page size in nv-p2p. – 4316020
The NVIDIA driver's kernel mode GPUDirect RDMA APIs that are used for Peer-direct support in MLNX_OFED and GPUDirect Storage are not supported on GH200 platforms when used with Linux kernels that are configured with the 4K page size. These APIs are not functional and might lead to a kernel memory corruption.
​
Users are strongly encouraged to move their software stack to the dma-buf APIs, which requires the open-source GPU driver, Linux kernel 5.12 or later, and NVIDIA Turing™ + GPU. Since the dma-buf APIs work correctly on 4K page kernels, using the APIs is ideal mitigation for this issue.
