厚声HV1007系列高压贴片电阻 额定电压2kV 封装2010 功率3/4W 温度系数100ppm/℃ 工作温度-55℃ ~ +155℃兼容AEC-Q200

​封装与结构​

2010（5.0mm×2.5mm×0.55mm）；200μm加厚电阻层；96%氧化铝陶瓷基板

蛇形走线布局降低电弧风险，比常规2010电阻节省35% PCB空间25

​电气特性​

额定电压：2kV；最大过载电压：4kV（脉宽＜5ms）；击穿电压：3.5kV

支持6kV/2Ω雷击浪涌防护2

​阻值与精度​

范围：1MΩ~10MΩ（E-24标准）；精度：±1%（F级）或±5%（J级）

高阻值型号（如10MΩ）需并联pF级电容抑制噪声1

​功率与温升​

额定功率：3/4W（0.75W@70℃）；降额曲线：100℃→0.6W，155℃→0.375W

需≥8mm²散热铜箔辅助散热5

​温度特性​

温度系数（TCR）：±100ppm/℃；工作温度：-55℃~+155℃

全温区阻值漂移≤1.5%5

​可靠性认证​

兼容AEC-Q200车规标准；通过IATF16949体系认证

机械强度可承受3mm PCB弯曲35

​高压电弧​

工作电压≤1.6kV（2kV×80%）

PCB开槽增加隔离间距；选用CTI≥600V基板材

耐压测试（5kV/1min）5

​温升失控​

155℃时功率≤0.375W

环境温度＞70℃时功率按0.8倍降额；强制风冷或散热铜箔

IR热成像仪监测温升（ΔT≤50℃）

​阻值漂移​

机械应力或湿气渗透

避免电阻位于PCB弯折区；三防漆覆盖保护

高低温循环测试（-55℃~125℃×500次）

​高频失真​

适用频率≤200kHz

＞200kHz时选用薄膜电阻；并联电容补偿寄生电容（1.2pF）

网络分析仪测试频响（10Hz~1MHz）

​焊接损伤​

回流焊峰值温度≤260℃

优化曲线：预热150℃→220℃（60s）→峰值260℃（＜5s）

焊点切片分析（空洞率＜15%）5

HV1007F1003T4E

2 kV

HV

2010

100 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F1004T4E

2 kV

HV

2010

1 MOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F1103T4E

2 kV

HV

2010

110 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F1203T4E

2 kV

HV

2010

120 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F1503T4E

2 kV

HV

2010

150 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F2203T4E

2 kV

HV

2010

220 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F3303T4E

2 kV

HV

2010

330 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F3603T4E

2 kV

HV

2010

360 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F3833T4E

2 kV

HV

2010

383 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F4703T4E

2 kV

HV

2010

470 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F4993T4E

2 kV

HV

2010

499 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F5103T4E

2 kV

HV

2010

510 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F6193T4E

2 kV

HV

2010

619 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F6493T4E

2 kV

HV

2010

649 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F6802T4E

2 kV

HV

2010

68 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F6803T4E

2 kV

HV

2010

680 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F6812T4E

2 kV

HV

2010

68.1 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F6813T4E

2 kV

HV

2010

681 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007F8253T4E

2 kV

HV

2010

825 kOhms

750 mW (3/4 W)

1%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0104T4E

2 kV

HV

2010

100 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0105T4E

2 kV

HV

2010

1 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0106T4E

2 kV

HV

2010

10 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0114T4E

2 kV

HV

2010

110 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0115T4E

2 kV

HV

2010

1.1 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0124T4E

2 kV

HV

2010

120 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0125T4E

2 kV

HV

2010

1.2 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0134T4E

2 kV

HV

2010

130 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0135T4E

2 kV

HV

2010

1.3 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0154T4E

2 kV

HV

2010

150 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0155T4E

2 kV

HV

2010

1.5 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0164T4E

2 kV

HV

2010

160 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0165T4E

2 kV

HV

2010

1.6 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0184T4E

2 kV

HV

2010

180 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0185T4E

2 kV

HV

2010

1.8 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0204T4E

2 kV

HV

2010

200 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0205T4E

2 kV

HV

2010

2 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0224T4E

2 kV

HV

2010

220 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0225T4E

2 kV

HV

2010

2.2 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0244T4E

2 kV

HV

2010

240 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0245T4E

2 kV

HV

2010

2.4 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0274T4E

2 kV

HV

2010

270 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0275T4E

2 kV

HV

2010

2.7 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0304T4E

2 kV

HV

2010

300 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0305T4E

2 kV

HV

2010

3 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0334T4E

2 kV

HV

2010

330 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0335T4E

2 kV

HV

2010

3.3 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0364T4E

2 kV

HV

2010

360 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0365T4E

2 kV

HV

2010

3.6 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0394T4E

2 kV

HV

2010

390 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0395T4E

2 kV

HV

2010

3.9 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0434T4E

2 kV

HV

2010

430 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0435T4E

2 kV

HV

2010

4.3 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0474T4E

2 kV

HV

2010

470 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0475T4E

2 kV

HV

2010

4.7 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0513T4E

2 kV

HV

2010

51 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0514T4E

2 kV

HV

2010

510 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0515T4E

2 kV

HV

2010

5.1 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0563T4E

2 kV

HV

2010

56 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0564T4E

2 kV

HV

2010

560 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0565T4E

2 kV

HV

2010

5.6 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0623T4E

2 kV

HV

2010

62 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0624T4E

2 kV

HV

2010

620 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0625T4E

2 kV

HV

2010

6.2 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0683T4E

2 kV

HV

2010

68 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0684T4E

2 kV

HV

2010

680 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0685T4E

2 kV

HV

2010

6.8 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0753T4E

2 kV

HV

2010

75 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0754T4E

2 kV

HV

2010

750 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0755T4E

2 kV

HV

2010

7.5 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0823T4E

2 kV

HV

2010

82 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0824T4E

2 kV

HV

2010

820 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0825T4E

2 kV

HV

2010

8.2 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0913T4E

2 kV

HV

2010

91 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0914T4E

2 kV

HV

2010

910 kOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade

HV1007J0915T4E

2 kV

HV

2010

9.1 MOhms

750 mW (3/4 W)

5%

100 PPM / C

- 55 C

+ 155 C

Automotive Grade
