Q-Learning算法实现与迷宫求解
引言
强化学习（Reinforcement Learning, RL）是机器学习的一个重要分支，它研究如何通过与环境的交互来学习最优行为策略。与监督学习和无监督学习不同，强化学习不需要标注的数据集，而是通过试错机制（Trial and Error）来最大化累积奖励。
Q-Learning是强化学习中最经典和基础的算法之一，它属于值函数方法（Value-based Methods）的范畴。本文将深入介绍Q-Learning算法的原理，并通过实现一个完整的迷宫求解游戏来展示其应用。
在这里插入图片描述
强化学习基础概念
核心要素
强化学习问题可以抽象为以下几个核心要素：
- 智能体（Agent）：学习者和决策者，能够感知环境并采取行动
- 环境（Environment）：智能体外部的一切，能够响应智能体的行动
- 状态（State）：对环境的描述，表示当前的情况
- 动作（Action）：智能体可以执行的操作
- 奖励（Reward）：环境对智能体动作的即时反馈
- 策略（Policy）：智能体在给定状态下选择动作的规则
马尔可夫决策过程（MDP）
强化学习问题通常被建模为马尔可夫决策过程（Markov Decision Process, MDP），由五元组 (S, A, P, R, γ) 定义：
- S：状态空间
- A：动作空间
- P：状态转移概率函数
- R：奖励函数
- γ：折扣因子（0 < γ ≤ 1）
价值函数
价值函数用于评估状态或状态-动作对的优劣：
- 状态价值函数 V(s)：从状态s出发遵循策略π的期望累积奖励
- 动作价值函数 Q(s, a)：在状态s执行动作a后遵循策略π的期望累积奖励
Bellman方程
Q-Learning的核心是Bellman最优方程： Q*(s, a) = E[r + γ * max Q*(s’, a’) | s, a]
这个方程表明：最优动作价值等于即时奖励加上折扣后的最优下一状态价值。
Q-Learning算法详解
算法原理
Q-Learning是一种离策略（Off-policy）时序差分（Temporal Difference）学习算法。它通过以下更新规则来学习最优Q函数：
Q(s, a) ← Q(s, a) + α * [r + γ * max Q(s’, a’) - Q(s, a)]
其中：
- α：学习率（Learning Rate）
- r：获得的即时奖励
- γ：折扣因子（Discount Factor）
- s’：下一个状态
- max Q(s’, a’)：下一个状态的最大Q值
探索与利用平衡
强化学习中的核心挑战是在探索（Exploration）和利用（Exploitation）之间找到平衡：
- 探索：尝试新的动作以发现更好的策略
- 利用：选择已知最优的动作以获得最大奖励
常用的策略包括：
- ε-贪心策略（ε-greedy）
- Softmax策略
- UCB（Upper Confidence Bound）
算法流程
- 初始化Q表为0或小随机值
- 对于每个回合：
- 初始化状态s
- 对于每个时间步：
- 使用ε-贪心策略从Q表选择动作a
- 执行动作a，观察奖励r和新状态s’
- 更新Q值：Q(s, a) ← Q(s, a) + α * [r + γ * max Q(s’, a’) - Q(s, a)]
- 更新状态：s ← s’
- 如果到达终止状态，结束回合
迷宫环境实现
环境设计
我们将实现一个简单的迷宫环境，包含：
- 网格世界（Grid World）
- 起点、终点和障碍物
- 四个基本动作：上、下、左、右
import numpy as np
import matplotlib.pyplot as plt
import matplotlib.patches as patches
from matplotlib.animation import FuncAnimation
from IPython.display import HTML
import random
class MazeEnvironment:
def __init__(self, width=10, height=10, obstacles=None):
self.width = width
self.height = height
self.obstacles = obstacles if obstacles else []
# 定义动作：0=上, 1=下, 2=左, 3=右
self.actions = [0, 1, 2, 3]
self.action_names = ['上', '下', '左', '右']
# 设置起点和终点
self.start = (0, 0)
self.goal = (width-1, height-1)
# 初始化智能体位置
self.reset()
def reset(self):
"""重置环境到初始状态"""
self.agent_pos = self.start
self.done = False
return self.get_state()
def get_state(self):
"""获取当前状态"""
return self.agent_pos[0] * self.width + self.agent_pos[1]
def step(self, action):
"""执行动作并返回新状态、奖励和是否结束"""
if self.done:
return self.get_state(), 0, True
# 保存当前位置
old_pos = self.agent_pos
# 根据动作更新位置
if action == 0: # 上
new_pos = (self.agent_pos[0], max(0, self.agent_pos[1] - 1))
elif action == 1: # 下
new_pos = (self.agent_pos[0], min(self.height - 1, self.agent_pos[1] + 1))
elif action == 2: # 左
new_pos = (max(0, self.agent_pos[0] - 1), self.agent_pos[1])
elif action == 3: # 右
new_pos = (min(self.width - 1, self.agent_pos[0] + 1), self.agent_pos[1])
# 检查是否碰到障碍物
if new_pos in self.obstacles:
new_pos = old_pos # 如果碰到障碍物，位置不变
self.agent_pos = new_pos
# 计算奖励
if self.agent_pos == self.goal:
reward = 100 # 到达终点的奖励
self.done = True
else:
# 距离终点的曼哈顿距离作为负奖励
distance = abs(self.agent_pos[0] - self.goal[0]) + \
abs(self.agent_pos[1] - self.goal[1])
reward = -1 - distance * 0.1 # 基础惩罚 + 距离惩罚
return self.get_state(), reward, self.done
def render(self, ax=None):
"""可视化环境"""
if ax is None:
fig, ax = plt.subplots(figsize=(8, 8))
# 清空画布
ax.clear()
# 绘制网格
for i in range(self.width + 1):
ax.axhline(i, color='black', linewidth=0.5)
ax.axvline(i, color='black', linewidth=0.5)
# 绘制障碍物
for obs in self.obstacles:
rect = patches.Rectangle(obs, 1, 1, linewidth=1,
edgecolor='black', facecolor='gray')
ax.add_patch(rect)
# 绘制起点
start_rect = patches.Rectangle(self.start, 1, 1, linewidth=1,
edgecolor='green', facecolor='lightgreen')
ax.add_patch(start_rect)
ax.text(self.start[0] + 0.5, self.start[1] + 0.5, 'S',
ha='center', va='center', fontsize=12, fontweight='bold')
# 绘制终点
goal_rect = patches.Rectangle(self.goal, 1, 1, linewidth=1,
edgecolor='red', facecolor='lightcoral')
ax.add_patch(goal_rect)
ax.text(self.goal[0] + 0.5, self.goal[1] + 0.5, 'G',
ha='center', va='center', fontsize=12, fontweight='bold')
# 绘制智能体
agent_circle = plt.Circle((self.agent_pos[0] + 0.5, self.agent_pos[1] + 0.5),
0.3, color='blue')
ax.add_patch(agent_circle)
ax.set_xlim(0, self.width)
ax.set_ylim(0, self.height)
ax.set_aspect('equal')
ax.set_title('迷宫环境')
return axQ-Learning智能体实现
class QLearningAgent:
def __init__(self, state_space_size, action_space_size, learning_rate=0.1,
discount_factor=0.9, epsilon=1.0, epsilon_decay=0.995,
epsilon_min=0.01):
self.state_space_size = state_space_size
self.action_space_size = action_space_size
self.learning_rate = learning_rate
self.discount_factor = discount_factor
self.epsilon = epsilon
self.epsilon_decay = epsilon_decay
self.epsilon_min = epsilon_min
# 初始化Q表
self.q_table = np.zeros((state_space_size, action_space_size))
def choose_action(self, state, training=True):
"""使用ε-贪心策略选择动作"""
if training and random.random() < self.epsilon:
return random.choice(range(self.action_space_size))
else:
return np.argmax(self.q_table[state])
def learn(self, state, action, reward, next_state, done):
"""更新Q表"""
current_q = self.q_table[state, action]
if done:
max_next_q = 0
else:
max_next_q = np.max(self.q_table[next_state])
new_q = current_q + self.learning_rate * \
(reward + self.discount_factor * max_next_q - current_q)
self.q_table[state, action] = new_q
# 更新ε值
if self.epsilon > self.epsilon_min:
self.epsilon *= self.epsilon_decay
def get_policy(self):
"""获取学习到的策略"""
return np.argmax(self.q_table, axis=1)训练过程
def train_agent(env, agent, episodes=1000, max_steps_per_episode=100):
"""训练Q-Learning智能体"""
episode_rewards = []
episode_lengths = []
epsilon_values = []
for episode in range(episodes):
state = env.reset()
total_reward = 0
steps = 0
for step in range(max_steps_per_episode):
# 选择动作
action = agent.choose_action(state)
# 执行动作
next_state, reward, done = env.step(action)
# 学习
agent.learn(state, action, reward, next_state, done)
# 更新状态
state = next_state
total_reward += reward
steps += 1
if done:
break
episode_rewards.append(total_reward)
episode_lengths.append(steps)
epsilon_values.append(agent.epsilon)
# 打印进度
if (episode + 1) % 100 == 0:
avg_reward = np.mean(episode_rewards[-100:])
print(f"Episode {episode + 1}/{episodes}")
print(f"Average Reward (last 100): {avg_reward:.2f}")
print(f"Epsilon: {agent.epsilon:.3f}")
print("-" * 50)
return episode_rewards, episode_lengths, epsilon_values可视化训练过程
def plot_training_progress(rewards, lengths, epsilons):
"""绘制训练进度图表"""
fig, axes = plt.subplots(3, 1, figsize=(10, 12))
# 计算移动平均
window_size = 100
rewards_ma = np.convolve(rewards, np.ones(window_size)/window_size, mode='valid')
lengths_ma = np.convolve(lengths, np.ones(window_size)/window_size, mode='valid')
# 绘制奖励
axes[0].plot(rewards, alpha=0.3, label='Episode Reward')
axes[0].plot(range(window_size-1, len(rewards)), rewards_ma, 'r-', label=f'Moving Average ({window_size} episodes)')
axes[0].set_title('Episode Rewards')
axes[0].set_xlabel('Episode')
axes[0].set_ylabel('Reward')
axes[0].legend()
axes[0].grid(True)
# 绘制步数
axes[1].plot(lengths, alpha=0.3, label='Episode Length')
axes[1].plot(range(window_size-1, len(lengths)), lengths_ma, 'g-', label=f'Moving Average ({window_size} episodes)')
axes[1].set_title('Episode Lengths')
axes[1].set_xlabel('Episode')
axes[1].set_ylabel('Steps')
axes[1].legend()
axes[1].grid(True)
# 绘制epsilon值
axes[2].plot(epsilons)
axes[2].set_title('Epsilon (Exploration Rate)')
axes[2].set_xlabel('Episode')
axes[2].set_ylabel('Epsilon')
axes[2].grid(True)
plt.tight_layout()
plt.show()测试训练好的智能体
def test_agent(env, agent, max_episodes=5, max_steps=100):
"""测试训练好的智能体"""
success_count = 0
for episode in range(max_episodes):
state = env.reset()
path = [state]
done = False
steps = 0
while not done and steps < max_steps:
# 不使用探索，直接选择最优动作
action = agent.choose_action(state, training=False)
next_state, reward, done = env.step(action)
path.append(next_state)
state = next_state
steps += 1
if done and env.agent_pos == env.goal:
success_count += 1
print(f"Episode {episode + 1}: 成功到达终点，用时 {steps} 步")
else:
print(f"Episode {episode + 1}: 未能在 {max_steps} 步内到达终点")
success_rate = success_count / max_episodes
print(f"\n成功率: {success_rate * 100:.1f}%")
return success_rate可视化学习到的策略
def visualize_policy(env, agent):
"""可视化学习到的策略"""
fig, ax = plt.subplots(figsize=(10, 10))
# 绘制环境
env.render(ax)
# 获取策略
policy = agent.get_policy()
# 绘制策略箭头
arrow_props = dict(arrowstyle='->', lw=2, color='black')
for i in range(env.width):
for j in range(env.height):
state = j * env.width + i
action = policy[state]
# 跳过障碍物、起点和终点
if (i, j) in env.obstacles or (i, j) == env.start or (i, j) == env.goal:
continue
# 计算箭头方向
if action == 0: # 上
dx, dy = 0, -0.3
elif action == 1: # 下
dx, dy = 0, 0.3
elif action == 2: # 左
dx, dy = -0.3, 0
else: # 右
dx, dy = 0.3, 0
# 绘制箭头
ax.arrow(i + 0.5, j + 0.5, dx, dy, **arrow_props)
ax.set_title('学习到的策略')
plt.show()创建动画展示智能体行为
def animate_agent_path(env, agent, max_steps=100):
"""创建动画展示智能体的路径"""
frames = []
state = env.reset()
done = False
steps = 0
while not done and steps < max_steps:
# 记录当前帧
fig, ax = plt.subplots(figsize=(8, 8))
env.render(ax)
# 保存图像
fig.canvas.draw()
image = np.frombuffer(fig.canvas.tostring_rgb(), dtype='uint8')
image = image.reshape(fig.canvas.get_width_height()[::-1] + (3,))
frames.append(image)
plt.close(fig)
# 选择动作并执行
action = agent.choose_action(state, training=False)
state, _, done = env.step(action)
steps += 1
return frames
def create_animation(frames, interval=200):
"""创建动画"""
fig, ax = plt.subplots(figsize=(8, 8))
ax.axis('off')
im = ax.imshow(frames[0])
def update(frame):
im.set_array(frames[frame])
return [im]
anim = FuncAnimation(fig, update, frames=len(frames), interval=interval, blit=True)
plt.close(fig)
return anim完整训练流程
# 创建迷宫环境
obstacles = [(2, 2), (2, 3), (2, 4), (5, 5), (5, 6), (5, 7), (7, 3), (7, 4)]
env = MazeEnvironment(width=10, height=10, obstacles=obstacles)
# 创建Q-Learning智能体
state_space_size = env.width * env.height
action_space_size = 4
agent = QLearningAgent(
state_space_size=state_space_size,
action_space_size=action_space_size,
learning_rate=0.1,
discount_factor=0.95,
epsilon=1.0,
epsilon_decay=0.995,
epsilon_min=0.01
)
# 训练智能体
print("开始训练...")
rewards, lengths, epsilons = train_agent(env, agent, episodes=1000)
# 绘制训练进度
plot_training_progress(rewards, lengths, epsilons)
# 测试智能体
print("\n测试智能体...")
success_rate = test_agent(env, agent, max_episodes=10)
# 可视化策略
print("\n可视化学习到的策略...")
visualize_policy(env, agent)
# 创建动画展示
print("\n生成智能体路径动画...")
frames = animate_agent_path(env, agent)
anim = create_animation(frames)
# 在Jupyter notebook中显示动画
# HTML(anim.to_jshtml())
# 保存动画为GIF
# anim.save('agent_path.gif', writer='pillow')Q-Learning的改进与变体
Double Q-Learning
标准Q-Learning存在最大值偏差问题。Double Q-Learning使用两个独立的Q表来缓解这个问题：
class DoubleQLearningAgent:
def __init__(self, state_space_size, action_space_size, learning_rate=0.1,
discount_factor=0.9, epsilon=1.0, epsilon_decay=0.995,
epsilon_min=0.01):
self.state_space_size = state_space_size
self.action_space_size = action_space_size
self.learning_rate = learning_rate
self.discount_factor = discount_factor
self.epsilon = epsilon
self.epsilon_decay = epsilon_decay
self.epsilon_min = epsilon_min
# 初始化两个Q表
self.q_table_a = np.zeros((state_space_size, action_space_size))
self.q_table_b = np.zeros((state_space_size, action_space_size))
def choose_action(self, state, training=True):
"""使用ε-贪心策略选择动作"""
if training and random.random() < self.epsilon:
return random.choice(range(self.action_space_size))
else:
# 使用两个Q表的平均值
avg_q = (self.q_table_a[state] + self.q_table_b[state]) / 2
return np.argmax(avg_q)
def learn(self, state, action, reward, next_state, done):
"""更新Q表"""
if random.random() < 0.5:
# 更新表A
current_q = self.q_table_a[state, action]
best_action = np.argmax(self.q_table_a[next_state])
max_next_q = self.q_table_b[next_state, best_action]
else:
# 更新表B
current_q = self.q_table_b[state, action]
best_action = np.argmax(self.q_table_b[next_state])
max_next_q = self.q_table_a[next_state, best_action]
if done:
max_next_q = 0
new_q = current_q + self.learning_rate * \
(reward + self.discount_factor * max_next_q - current_q)
if random.random() < 0.5:
self.q_table_a[state, action] = new_q
else:
self.q_table_b[state, action] = new_q
# 更新ε值
if self.epsilon > self.epsilon_min:
self.epsilon *= self.epsilon_decay优先经验回放
虽然传统上与深度Q网络结合使用，但也可以在表格型Q-Learning中应用优先经验回放的思路：
class PrioritizedQLearningAgent:
def __init__(self, state_space_size, action_space_size, learning_rate=0.1,
discount_factor=0.9, epsilon=1.0, epsilon_decay=0.995,
epsilon_min=0.01, buffer_size=10000):
self.state_space_size = state_space_size
self.action_space_size = action_space_size
self.learning_rate = learning_rate
self.discount_factor = discount_factor
self.epsilon = epsilon
self.epsilon_decay = epsilon_decay
self.epsilon_min = epsilon_min
# 初始化Q表
self.q_table = np.zeros((state_space_size, action_space_size))
# 经验回放缓冲区
self.buffer = []
self.buffer_size = buffer_size
self.priorities = np.zeros(buffer_size)
self.alpha = 0.6 # 优先级指数
def store_experience(self, state, action, reward, next_state, done):
"""存储经验并计算优先级"""
# 计算TD误差作为优先级
current_q = self.q_table[state, action]
if done:
target_q = reward
else:
target_q = reward + self.discount_factor * np.max(self.q_table[next_state])
td_error = abs(target_q - current_q)
experience = (state, action, reward, next_state, done)
if len(self.buffer) < self.buffer_size:
self.buffer.append(experience)
self.priorities[len(self.buffer)-1] = td_error
else:
# 找到最小优先级的位置进行替换
min_idx = np.argmin(self.priorities)
if td_error > self.priorities[min_idx]:
self.buffer[min_idx] = experience
self.priorities[min_idx] = td_error
def sample_experience(self):
"""根据优先级采样经验"""
if len(self.buffer) == 0:
return None
# 将优先级转换为概率
priorities = self.priorities[:len(self.buffer)]
probs = priorities ** self.alpha
probs /= probs.sum()
# 根据概率采样
idx = np.random.choice(len(self.buffer), p=probs)
return self.buffer[idx]
def learn(self):
"""从经验回放缓冲区中学习"""
experience = self.sample_experience()
if experience is None:
return
state, action, reward, next_state, done = experience
current_q = self.q_table[state, action]
if done:
max_next_q = 0
else:
max_next_q = np.max(self.q_table[next_state])
new_q = current_q + self.learning_rate * \
(reward + self.discount_factor * max_next_q - current_q)
self.q_table[state, action] = new_q总结与展望
本文详细介绍了Q-Learning算法的原理和实现，并通过一个完整的迷宫求解项目展示了其应用。通过这个实践，你应该能够：
- 理解强化学习的基本概念和框架
- 掌握Q-Learning算法的核心原理和实现细节
- 学会设计简单的强化学习环境
- 了解如何评估和可视化强化学习智能体的性能
Q-Learning的优势与局限
优势：
- 简单直观，易于理解和实现
- 不需要环境模型（模型无关）
- 保证收敛到最优Q函数（满足一定条件）
- 适用于离散状态和动作空间
局限：
- Q表大小随状态数量指数增长（维度灾难）
- 不适用于连续动作空间
- 训练效率可能较低
- 对超参数敏感
进一步探索
- 深度Q网络（DQN）：使用神经网络近似Q函数，处理大规模状态空间
- 策略梯度方法：直接学习策略函数，如REINFORCE、A2C、PPO等
- Actor-Critic方法：结合值函数和策略优化的优势
- 多智能体强化学习：研究多个智能体的协作与竞争
- 分层强化学习：学习层次化的策略
- 元强化学习：学习如何快速适应新任务
- 离线强化学习：从固定的数据集中学习策略
强化学习正在快速发展，在游戏、机器人控制、自动驾驶、推荐系统等领域都有广泛应用。掌握Q-Learning等基础算法是深入理解强化学习的重要第一步。希望本文能够为你打下坚实的基础，激发你进一步探索强化学习的兴趣。
本文参与 腾讯云自媒体同步曝光计划，分享自作者个人站点/博客。
原始发表：2026-01-13，如有侵权请联系 cloudcommunity@tencent.com 删除
评论
登录后参与评论
推荐阅读
目录
腾讯云开发者
Copyright © 2013 - 2026 Tencent Cloud. All Rights Reserved. 腾讯云 版权所有
深圳市腾讯计算机系统有限公司 ICP备案/许可证号：粤B2-20090059
粤公网安备44030502008569号
腾讯云计算（北京）有限责任公司 京ICP证150476号 | 京ICP备11018762号
