十分钟就能上手Prometheus与Grafana监控SpringBoot项目

<!--这个依赖用于健康检查，审计，指标收集-->
<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-actuator</artifactId>
</dependency>
<!--这个依赖用于把数据转换为prometheus格式使用-->
<dependency>
    <groupId>io.micrometer</groupId>
    <artifactId>micrometer-registry-prometheus</artifactId>
    <version>1.9.2</version>
</dependency>

spring:
  application:
    name: springboot-prometheus
#对外暴露哪些指标
management:
  endpoints:
    web:
      exposure:
        include: "*"
  #激活promethues并转换为对应的promethues数据
  endpoint:
    prometheus:
      enabled: true
    health:
      show-details: always
  #允许对应的数据指标被导出
  metrics:
    export:
      prometheus:
        enabled: true
server:
  port: 8081

@SpringBootApplication
public class SpringbootdemoApplication {

    public static void main(String[] args) {
        SpringApplication.run(SpringbootdemoApplication.class, args);
    }

    // 为实例设置自定义标签
    @Bean
    MeterRegistryCustomizer<MeterRegistry> configurer(
            @Value("${spring.application.name}") String name){
        return registry -> registry.config().commonTags("application",name);
    }

}

#my global config
global:
  scrape_interval:     15s # Set the scrape interval to every 15 seconds. Default is every 1 minute.
  evaluation_interval: 15s # Evaluate rules every 15 seconds. The default is every 1 minute.
  # scrape_timeout is set to the global default (10s).

# Alertmanager configuration
alerting:
  alertmanagers:
  - static_configs:
    - targets:
      # - alertmanager:9093

# Load rules once and periodically evaluate them according to the global 'evaluation_interval'.
rule_files:
  # - "first_rules.yml"
  # - "second_rules.yml"

# A scrape configuration containing exactly one endpoint to scrape:
# Here it's Prometheus itself.
scrape_configs:
  # The job name is added as a label `job=<job_name>` to any timeseries scraped from this config.
  - job_name: 'prometheus'

    # metrics_path defaults to '/metrics'
    # scheme defaults to 'http'.

    static_configs:
      - targets: ['localhost:9090']
### 以下内容为springboot的配置，主要是这个地方
  - job_name: 'springboot_promethues'
    scrape_interval: 5s
    metrics_path: '/actuator/prometheus'
    static_configs:
      - targets: ['localhost:8081']

docker run -d --name=prometheus -v /etc/prometheus/prometheus.yml:/etc/prometheus/prometheus.yml -p 9090:9090 bitnami/prometheus:latest
