深入实践：SonarQube 在 C/C++ 大规模代码审查中的工程化指南

# 专用服务器配置建议
CPU: 8核以上（需支持AVX指令集）
内存: 16GB（SonarQube Server分配12GB，Scanner 4GB）
存储: SSD硬盘，预留代码体积x3的空间

# 创建持久化卷并设置ES
内存参数docker run -d --name sonarqube \
  -p 9000:9000 \
  -v sonarqube_data:/opt/sonarqube/data \
  -v sonarqube_extensions:/opt/sonarqube/extensions \
  -e SONAR_ES_BOOTSTRAP_CHECKS_DISABLE=true \
  -e SONAR_WEB_JAVAOPTS="-Xmx4g -Xms2g" \  sonarqube:community

# 生成高强度密码（示例）
openssl rand -base64 16

wget https://binaries.sonarsource.com/Distribution/sonar-scanner-cli/sonar-scanner-5.0.1.3006-linux.zip
unzip sonar-scanner-*.zip -d /opt
echo 'export PATH=$PATH:/opt/sonar-scanner/bin' >> ~/.bashrc

sonar-scanner.bat -v Version 5.0.1.3006

#CMakeLists.txt 关键配置
set(CMAKE_EXPORT_COMPILE_COMMANDS ON)
if(CMAKE_BUILD_TYPE STREQUAL "Sonar")
  add_compile_options(-g -O0 --coverage)
endif()
  # 生成步骤
  mkdir build_sonar && cd build_sonar
  cmake -DCMAKE_BUILD_TYPE=Sonar ..
  mv compile_commands.json ../.sonar/

#Ubuntu/Debian 安装Bear
sudo apt-get install bear
# 复杂构建系统的完整捕获（以Makefile为例）
bear -- intercept-build --cd /project/src \
make -j8 CC=clang CXX=clang++
# 验证编译数据库完整性
jq '. | length' compile_commands.json  # 应匹配实际编译文件数

#多模块项目配置示例
sonar.projectKey=my_product_v2
sonar.projectVersion=2.3.0
sonar.scm.provider=git
sonar.cfamily.build-wrapper-output=build/sonar
# 代码结构配置
sonar.sources=src/core,src/modules
sonar.tests=test/unitsonar.exclusions=**/legacy/**/*.cpp
# 编译数据库配置sonar.cfamily.compile-commands=build/compile_commands.json
sonar.cfamily.cache.enabled=true  # 启用缓存提升扫描速度

# 自定义规则集
sonar.cxx.jsonCompilationDatabase=/abs/path/to/compile_commands.json
sonar.cxx.errorRecovery.enabled=true

stages:
- sonar-precheck
- build
- sonar-analysis
sonar_precheck:
stage: sonar-precheck
image: sonarsource/sonar-scanner-cli
script:
- sonar-scanner
-Dsonar.projectKey=$CI_PROJECT_NAME
-Dsonar.projectVersion=$CI_COMMIT_SHORT_SHA
-Dsonar.analysis.mode=preview
-Dsonar.gitlab.commit_sha=$CI_COMMIT_SHA
-Dsonar.gitlab.ref_name=$CI_COMMIT_REF_NAME build_analyze:
stage: build
image: gcc:12
script:
- mkdir -p build && cd build
- cmake -DCMAKE_EXPORT_COMPILE_COMMANDS=ON ..
- intercept-build make -j4
- mv compile_commands.json ../.sonar/
sonar_analysis:
stage: sonar-analysis
image: sonarsource/sonar-scanner-cli
dependencies:
- build_analyze
script:
- sonar-scanner
-Dsonar.login=$SONAR_TOKEN
-Dsonar.branch.name=$CI_COMMIT_REF_NAME
 allow_failure: false

pipeline {
  agent { label 'sonar-scanner' }
  environment {
    SCANNER_HOME = tool 'SonarScanner-5.0'
     }
     stages {
       stage('Build with Bear') {
             agent { label 'c++-builder' }
             steps {
               sh '''
               bear -- make -j8
               mkdir -p .sonar
               cp compile_commands.json .sonar/
               '''
                   }
               }
                stage('Sonar Analysis') {
                     steps {
                      withSonarQubeEnv('SonarQube-Prod') {
                       sh "${SCANNER_HOME}/bin/sonar-scanner \
                        -Dsonar.projectKey=${JOB_NAME} \
                        -Dsonar.cfamily.threads=8"
                        }
                      }
                    }
                  }
                  post {
                  failure {
                  slackSend color: 'danger', message: "SonarQube分析失败: ${env.BUILD_URL}"
                          }
                        }
  }

// 文件级忽略
#pragma GCC diagnostic ignored "-Wsonar-issue"  // NOSONAR
void sensitive_function() { // NOSONAR: legacy code  // 行内忽略
char buffer1024; // NOSONAR: stack usage validated
}

-- 零容忍策略示例
metric_conditions:
  - metric = new_violations and op = GT and error = 0
  - metric = coverage and op = LT and warning = 80
  - metric = duplicated_lines_density and op = GT and error = 5

商业版集群配置示例
sonar-scanner -Dsonar.host.url=http://sonar-master:9000 \
  -Dsonar.worker.node=node05 \
  -Dsonar.cfamily.threads=16 \
  -Dsonar.scm.disabled=true

仅扫描差异代码（商业版功能）
sonar.inclusions=src/modules/payment/**
sonar.exclusions=**/deprecated/**
sonar.scm.provider=gitsonar.scm.revision=HEAD~1

修改 $SONARQUBE_HOME/conf/sonar.properties
sonar.ce.javaOpts=-Xmx8g -XX:+HeapDumpOnOutOfMemoryError
sonar.web.javaOpts=-Xmx4g -XX:MaxMetaspaceSize=512m
# Linux内核参数优化
sysctl -w vm.max_map_count=262144

validate_compile_commands.py
import json
with open('compile_commands.json') as f:
  data = json.load(f)
  for cmd in data:
    assert 'directory' in cmd, "Missing directory field"
    assert 'command' in cmd or 'arguments' in cmd, "Invalid command format"
    print(f"Validated {cmd'file'}")

使用SonarQube API生成质量报告
curl -u $SONAR_TOKEN: \
"http://sonar-server/api/measures/component?component=my_project&metricKeys=violations,bugs,code_smells" \
| jq '.component.measures'
