社区首页 >专栏 >Google Earth Engine——美国国家环境预测中心（NCEP）的气候预测系统再分析（CFSR）是作为一个全球性的、高分辨率的、大气-海洋-陆地表面-海冰耦合系统设计和执行的数据集

Google Earth Engine——美国国家环境预测中心（NCEP）的气候预测系统再分析（CFSR）是作为一个全球性的、高分辨率的、大气-海洋-陆地表面-海冰耦合系统设计和执行的数据集

此星光明

发布于 2024-02-02 04:14:33

96700

代码可运行

文章被收录于专栏：GEE数据专栏，GEE学习专栏，GEE错误集等专栏GEE数据专栏，GEE学习专栏，GEE错误集等专栏

运行总次数：0

代码可运行

The National Centers for Environmental Prediction (NCEP) Climate Forecast System Reanalysis (CFSR) was designed and executed as a global, high-resolution, coupled atmosphere-ocean-land surface-sea ice system to provide the best estimate of the state of these coupled domains over the 32-year period of record from January 1979 to March 2011. It has been extended as an operational real-time product. The data in Earth Engine are only present starting from December 13, 2018.

Forecasts are initialized four times per day (0000, 0600, 1200, and 1800 UTC). We ingest only a subset of bands from files matching cdas1.t??z.pgrbh03|00.grib2 i.e. files of only 0-hour and 3-hour forecasts as the others are omitted. The forecast length is indicated by the 'forecast_hour' metadata field.

Some images contain only a subset of bands. Using this dataset with both "00" and "03" forecast types will require you to cast the bands across the collection.

美国国家环境预测中心（NCEP）的气候预测系统再分析（CFSR）是作为一个全球性的、高分辨率的、大气-海洋-陆地表面-海冰耦合系统设计和执行的，以提供1979年1月至2011年3月32年记录期间这些耦合领域状态的最佳估计。它已被扩展为一个实用的实时产品。地球引擎中的数据只从2018年12月13日开始出现。

预测每天初始化四次（0000、0600、1200和1800 UTC）。我们只从匹配cdas1.t??z.pgrbh03|00.grib2的文件中摄取一个波段子集，即只摄取0小时和3小时的预报文件，因为其他的都省略了。预报长度由 "预报_小时 "元数据字段表示。

有些图像只包含一个波段的子集。使用这个数据集的 "00 "和 "03 "预报类型将要求你在整个集合中投下波段。

Dataset Availability

2018-12-13T00:00:00 - 2021-09-30T00:00:00

Dataset Provider

NOAA NWS National Centers for Environmental Prediction (NCEP)

Collection Snippet

ee.ImageCollection("NOAA/CFSR")

Resolution

55660 meters

Bands Table

Name	Description	Min*	Max*	Units
u-component_of_wind_hybrid	u-component of wind at Hybrid level for 00 and 03 forecast	-47.24	44.33	m/s
v-component_of_wind_hybrid	v-component of wind at Hybrid level for 00 and 03 forecast	-45.45	46.36	m/s
Albedo_surface_3_Hour_Average	Albedo 3 hour average at ground or water surface for 03 forecast	0	91.59999847	%
Canopy_water_evaporation_surface_3_Hour_Average	Canopy water evaporation 3 hour average at ground or water surface for 03 forecast	0	746	W/m^2
Categorical_Rain_surface	Categorical Rain at ground or water surface for 00 and 03 forecast	0	1	INT
Categorical_Rain_surface_3_Hour_Average	Categorical Rain 3 hour average at ground or water surface for 03 forecast	0	1	INT
Categorical_Freezing_Rain_surface_3_Hour_Average	Categorical freezing rain 3 hour average at ground or water surface for 03 forecast	0	1	INT
Categorical_Ice_Pellets_surface_3_Hour_Average	Categorical ice pellets 3 hour average at ground or water surface for 03 forecast	0	1	INT
Categorical_Snow_surface_3_Hour_Average	Categorical snow 3 hour average at ground or water surface for 03 forecast	0	1	INT
Clear_Sky_Downward_Long_Wave_Flux_surface_3_Hour_Average	Clear Sky Downward Long Wave Flux 3 hour average at ground or water surface for 03 forecast	56	483	W/m^2
Clear_Sky_Downward_Solar_Flux_surface_3_Hour_Average	Clear Sky Downward Solar Flux 3 hour average at ground or water surface for 03 forecast	0	1142	W/m^2
Clear_Sky_Upward_Long_Wave_Flux_surface_3_Hour_Average	Clear Sky Upward Long Wave Flux 3 hour average at ground or water surface for 03 forecast	78	698	W/m^2
Clear_Sky_Upward_Solar_Flux_atmosphere_top_3_Hour_Average	Clear Sky Upward Solar Flux 3 hour average at ground or water surface for 03 forecast	0	767	W/m^2
Clear_sky_UV-B_Downward_Solar_Flux_surface_3_Hour_Average	Clear Sky UV-B Downward Solar Flux 3 hour average at ground or water surface for 03 forecast	0	24.77	W/m^2
Cloud_water_entire_atmosphere_single_layer	Cloud water at entire atmosphere layer for 00 and 03 forecast	0	19	kg/m^2
Cloud_Work_Function_entire_atmosphere_single_layer_3_Hour_Average	Cloud work function 3 hour average at entire atmosphere layer for 03 forecast	0	5791	J/kg
Convective_available_potential_energy_surface	Convective available potential energy at ground or water surface for 00 and 03 forecast	0	6069	J/kg
Convective_available_potential_energy_pressure_difference_layer	Convective available potential energy at specified pressure difference from ground to level layer for 03 forecast	0	5559	J/kg
Convective_Precipitation_Rate_surface_3_Hour_Average	Convective precipitation rate 3 hour average at ground or water surface for 03 forecast	0	0.002	kg/(m^2/s)
Convective_precipitation_surface_3_Hour_Accumulation	Convective precipitation 3 hour average at ground or water surface for 03 forecast	0	19.2	kg/m^2
Direct_Evaporation_from_Bare_Soil_surface_3_Hour_Average	Direct evaporation from bare soil surface 3 hour average at ground or water surface for 03 forecast	0	767	W/m^2
Downward_Long-Wave_Radp_Flux_surface	Downward Long-Wave Rad. Flux at ground or water surface for 00 and 03 forecast	60	530	W/m^2
Downward_Long-Wave_Radp_Flux_surface_3_Hour_Average	Downward Long-Wave Rad. Flux 3 hour average at ground or water surface for 03 forecast	60	508	W/m^2
Downward_Short-Wave_Radiation_Flux_surface	Downward Short-Wave Radiation Flux at ground or water surface for 00 and 03 forecast	0	1224	W/m^2
Downward_Short-Wave_Radiation_Flux_surface_3_Hour_Average	Downward Short-Wave Radiation Flux 3 hour average at ground or water surface for 03 forecast	0	1142	W/m^2
Downward_Short-Wave_Radiation_Flux_atmosphere_top_3_Hour_Average	Downward Short-Wave Radiation Flux atmosphere top 3 hour average at ground or water surface for 03 forecast	0	1382	W/m^2
Exchange_Coefficient_surface	Exchange Coefficient at ground or water surface for 00 and 03 forecast	0	0.69	(kg/m^3)/(m/s)
Frictional_Velocity_surface	Frictional Velocity at ground or water surface for 00 and 03 forecast	0.002	3.5	m/s
Ground_Heat_Flux_surface	Ground Heat Flux at ground or water surface for 00 and 03 forecast	-459	683	W/m^2
Ground_Heat_Flux_surface_3_Hour_Average	Ground Heat Flux 4 hour average at ground or water surface for 03 forecast	-170	538	W/m^2
Ice_cover_surface	Ice cover at ground or water surface for 00 and 03 forecast	0	1	INT
Ice_thickness_surface	Ice thickness at ground or water surface for 00 and 03 forecast	0	4.76	m
Land_cover_0__sea_1__land_surface	Land cover (0 = sea, 1 = land) at ground or water surface for 00 and 03 forecast	0	1	INT
Latent_heat_net_flux_surface	Latent heat net flux at ground or water surface for 00 and 03 forecast	-399	1675	W/m^2
Latent_heat_net_flux_surface_3_Hour_Average	Latent heat net flux 3 hour average at ground or water surface for 03 forecast	-305	1250	W/m^2
Liquid_Volumetric_Soil_Moisture_non_Frozen_depth_below_surface_layer_5_cm	Liquid Volumetric Soil Moisture (non Frozen) 5 cm depth below land surface layer	0.03	1	DOUBLE
Liquid_Volumetric_Soil_Moisture_non_Frozen_depth_below_surface_layer_25_cm	Liquid Volumetric Soil Moisture (non Frozen) 25 cm depth below land surface layer	0.028	1	DOUBLE
Liquid_Volumetric_Soil_Moisture_non_Frozen_depth_below_surface_layer_70_cm	Liquid Volumetric Soil Moisture (non Frozen) 50 cm depth below land surface layer	0.028	1	DOUBLE
Liquid_Volumetric_Soil_Moisture_non_Frozen_depth_below_surface_layer_150_cm	Liquid Volumetric Soil Moisture (non Frozen) 150 cm depth below land surface layer	0.028	1	DOUBLE
Maximum_temperature_height_above_ground_3_Hour_Interval	Maximum temperature for 3 Hour Interval at specified height level above ground for 03 forecast	201.39	327.7	K
Minimum_temperature_height_above_ground_3_Hour_Interval	Minimum temperature for 3 Hour Interval at specified height level above ground for 03 forecast	201	321.89	K
Maximum_specific_humidity_at_2m_height_above_ground_3_Hour_Interval	Maximum specific humidity for 3 Hour Interval at 2m specified height level above ground for 03 forecast	0	0.036	kg/kg
Minimum_specific_humidity_at_2m_height_above_ground_3_Hour_Interval	Minimum specific humidity for 3 Hour Interval at 2m specified height level above ground for 03 forecast	0	0.024	kg/kg
Momentum_flux_u-component_surface_3_Hour_Average	Momentum flux, u-component 3 hour average at ground or water surface for 03 forecast	-6.56	8.25	N/m^2
Momentum_flux_v-component_surface_3_Hour_Average	Momentum flux, u-component 3 hour average at ground or water surface for 03 forecast	-6.17	7.22	N/m^2
Plant_Canopy_Surface_Water_surface	Plant Canopy Surface Water at ground or water surface for 00 and 03 forecast	0	0.5	kg/m^2
Planetary_Boundary_Layer_Height_surface	Planetary Boundary Layer Height at ground or water surface for 00 and 03 forecast	17	6590	m
Potential_Evaporation_Rate_surface	Potential Evaporation Rate at ground or water surface for 00 and 03 forecast	-150	5617	W/m^2
Potential_Evaporation_Rate_surface_3_Hour_Average	Potential Evaporation Rate 3 hour average at ground or water surface for 03 forecast	-120	5263	W/m^2
Precipitation_rate_surface_3_Hour_Average	Precipitable rate 3 hour average at ground or water surface for 03 forecast	0	0.022	kg/m^2s
Precipitable_water_entire_atmosphere_single_layer	Precipitable water at entire atmosphere layer for 00 and 03 forecast	-0.6	99.09	kg/m^2
Precipitable_water_pressure_difference_layer	Precipitable water at specified pressure difference from ground to level layer for 00 forecast	0	7.94	kg/m^2
Pressure_msl	Pressure at Mean sea level for 03 forecast	92406.39	106907.89	Pa
Pressure_reduced_to_MSL_msl	Pressure reduced to MSL at Mean sea level for 00 and 03 forecast	92492.8	106667.79	Pa
Pressure_surface	Pressure at ground or water surface for 00 and 03 forecast	48110	105600	Pa
Relative_humidity_entire_atmosphere_single_layer	Relative humidity at entire atmosphere layer for 00 and 03 forecast	0	96	%
Sensible_heat_net_flux_surface	Sensible heat net flux at ground or water surface for 00 and 03 forecast	-1582	2500	W/m^2
Sensible_heat_net_flux_surface_3_Hour_Average	Sensible heat net flux 3 hour average at ground or water surface for 03 forecast	-977	1202	W/m^2
Snow_Cover_surface_3_Hour_Average	Snow cover 3 hour average at ground or water surface for 03 forecast	0	100	%
Snow_depth_surface	Snow depth at ground or water surface for 00 and 03 forecast	0	4.55	m
Snow_Phase_Change_Heat_Flux_surface_3_Hour_Average	Snow phase change hear flux 3 hour average at ground or water surface for 03 forecast	-405	911	W/m^2
Soil_moisture_content_depth_below_surface_layer	Soil moisture content at Depth below land surface layer for 00 and 03 forecast	62.01	2000.05	kg/m^2
Soil_type_surface	Soil type at ground or water surface for 00 and 03 forecast	1	9	INT
Storm_Surface_Runoff_surface_3_Hour_Accumulation	Strom surface runoff 3 hour accumulation at ground or water surface for 03 forecast	0	193.12	kg/m^2
Sublimation_evaporation_from_snow_surface_3_Hour_Average	Sublimation (evaporation from snow) 3 hour average at ground or water surface for 03 forecast	0	742	W/m^2
Specific_humidity_height_above_ground	Specific humidity at Specified height level above ground for 00 forecast	0.001	0.036	kg/kg
Surface_Lifted_Index_surface	Surface Lifted Index at ground or water surface for 00 and 03 forecast	-15.8	57.2	K
Surface_roughness_surface	Surface roughness at ground or water surface for 00 and 03 forecast	0	2.7	m
Surface_Slope_Type_surface	Surface Slope Type at ground or water surface for 00 and 03 forecast	1	9	index
Temperature_depth_below_surface_layer_5_cm	Temperature 5cm depth below land surface layer for 00 and 03 forecast	219.127	323.104	K
Temperature_depth_below_surface_layer_25_cm	Temperature 25cm epth below land surface layer for 00 and 03 forecast	220.288	313.299	K
Temperature_depth_below_surface_layer_70_cm	Temperature 70 cm depth below land surface layer for 00 and 03 forecast	218.704	310.007	K
Temperature_depth_below_surface_layer_150_cm	Temperature 150cm depth below land surface layer for 00 and 03 forecast	218.925	307.662	K
Temperature_height_above_ground	Temperature at Specified height level above ground for 00 forecast	201.17	325.763	K
Temperature_surface	Temperature at ground or water surface for 00 and 03 forecast	192.569	339.173	K
Total_cloud_cover_convective_cloud	Total cloud cover at Convective cloud layer for 00 forecast	0	100	%
Total_ozone_entire_atmosphere_single_layer	Total ozone at entire atmosphere layer for 00 and 03 forecast	177	571.4	DU
Total_precipitation_surface_3_Hour_Accumulation	Total precipitation 3 hour average at ground or water surface for 03 forecast	0	239	kg/m^2
Transpiration_surface_3_Hour_Average	Transpiration surface 3 hour average at ground or water surface for 03 forecast	0	680	W/m^2
Upward_Long-Wave_Radp_Flux_surface	Upward Long-Wave Rad. Flux at ground or water surface for 00 and 03 forecast	135	611	W/m^2
Upward_Long-Wave_Radp_Flux_surface_3_Hour_Average	Upward Long-Wave Radiation Flux 3 hour average at ground or water surface for 03 forecast	78	703	W/m^2
Upward_Long-Wave_Radp_Flux_atmosphere_top_3_Hour_Average	Upward Long-Wave Radiation Flux 3 hour average at nominal top of the atmosphere for 03 forecast	69	384	W/m^2
Upward_Short-Wave_Radiation_Flux_surface	Upward Short-Wave Radiation Flux at ground or water surface for 00 and 03 forecast	0	869	W/m^2
Upward_Short-Wave_Radiation_Flux_surface_3_Hour_Average	Upward Short-Wave Radiation Flux 3 hour average at ground or water surface for 03 forecast	0	806	W/m^2
Upward_Short-Wave_Radiation_Flux_atmosphere_top_3_Hour_Average	Upward Short-Wave Radiation Flux 3 hour average at nominal top of the atmosphere for 03 forecast	0	1049	W/m^2
UV-B_Downward_Solar_Flux_surface_3_Hour_Average	UV-B Downward Solar Flux 3 hour average at ground or water surface for 03 forecast	0	24.7	W/m^2
Vegetation_surface	Vegetation at ground or water surface for 00 and 03 forecast	0	99	%
Vegetation_Type_surface	Vegetation Type at ground or water surface for 00 and 03 forecast	1	13	INT
Volumetric_Soil_Moisture_Content_depth_below_surface_layer_5_cm	Volumetric soil moisture content 5cm below surface layer for 00 and 03 forecast	0.03	1	fraction
Volumetric_Soil_Moisture_Content_depth_below_surface_layer_25_cm	Volumetric soil moisture content 25cm below surface layer for 00 and 03 forecast	0.028	1	fraction
Volumetric_Soil_Moisture_Content_depth_below_surface_layer_70_cm	Volumetric soil moisture content 70cm below surface layer for 00 and 03 forecast	0.028	1	fraction
Volumetric_Soil_Moisture_Content_depth_below_surface_layer_150_cm	Volumetric soil moisture content 150cm below surface layer for 00 and 03 forecast	0.028	1	fraction
Water_equivalent_of_accumulated_snow_depth_surface	Water equivalent of accumulated snow depth at ground or water surface for 00 and 03 forecast	0	458.82	kg/m^2
Water_runoff_surface_3_Hour_Accumulation	Water runoff 3 hour accumulation at ground or water surface for 03 forecast	0	193.12	kg/m^2

* = Values are estimated

数据属性：

Name	Type	Description
forecast_hour	Int	Duration of forecast in hours

数据引用：

Saha, S., S. Moorthi, H. Pan, X. Wu, J. Wang, and Coauthors, 2010: The NCEP Climate Forecast System Reanalysis. Bulletin of the American Meteorological Society, 91, 1015–1057. doi:10.1175/2010BAMS3001.1

数据说明：

NOAA data, information, and products, regardless of the method of delivery, are not subject to copyright and carry no restrictions on their subsequent use by the public. Once obtained, they may be put to any lawful use. The forgoing data is in the public domain and is being provided without restriction on use and distribution. For more information visit the NWS disclaimer site.

代码：

var dataset = ee.ImageCollection('NOAA/CFSR')
                  .filter(ee.Filter.date('2019-04-01', '2019-04-07'));
var temperatureSurface = dataset.select('Temperature_surface');
var visParams = {
  min: 192.0,
  max: 339.0,
  palette: ["blue", "purple", "cyan", "green", "yellow", "red"]
};
Map.setCenter(-88.6, 26.4, 1);
Map.addLayer(temperatureSurface, visParams, 'Temperature Surface');

The National Centers for Environmental Prediction (NCEP) Climate Forecast System (CFS) is a fully coupled model representing the interaction between the Earth's atmosphere, oceans, land, and sea ice. CFS was developed at the Environmental Modeling Center (EMC) at NCEP. The operational CFS was upgraded to version 2 (CFSv2) on March 30, 2011.

Forecasts are initialized four times per day (0000, 0600, 1200, and 1800 UTC). This is the same model that was used to create the NCEP Climate Forecast System Reanalysis (CFSR), and the purpose of the CFSv2 dataset is to extend CFSR. We ingest only a subset of bands from files matching cdas1.t??z.sfluxgrbf06.grib2.

For more information about CFS, please see the CFS NOAA site.

CFSV2: NCEP Climate Forecast System Version 2, 6-Hourly Products

Dataset Availability

1979-01-01T00:00:00 - 2021-09-30T00:00:00

Dataset Provider

NOAA NWS National Centers for Environmental Prediction (NCEP)

Collection Snippet

Copied

ee.ImageCollection("NOAA/CFSV2/FOR6H")

代码：

var dataset = ee.ImageCollection('NOAA/CFSV2/FOR6H')
                  .filter(ee.Filter.date('2018-03-01', '2018-03-14'));
var temperatureAboveGround = dataset.select('Temperature_height_above_ground');
var visParams = {
  min: 220.0,
  max: 310.0,
  palette: ['blue', 'purple', 'cyan', 'green', 'yellow', 'red'],
};
Map.setCenter(-88.6, 26.4, 1);
Map.addLayer(temperatureAboveGround, visParams, 'Temperature Above Ground');
