操作系统内核中的初始化工作

void main(void)  /* This really IS void, no error here. */
{   /* The startup routine assumes (well, ...) this */
/*
 * Interrupts are still disabled. Do necessary setups, then
 * enable them
 */
 ROOT_DEV = ORIG_ROOT_DEV;
 drive_info = DRIVE_INFO;
 memory_end = (1<<20) + (EXT_MEM_K<<10);
 memory_end &= 0xfffff000;
 if (memory_end > 16*1024*1024)
  memory_end = 16*1024*1024;
 if (memory_end > 12*1024*1024)
  buffer_memory_end = 4*1024*1024;
 else if (memory_end > 6*1024*1024)
  buffer_memory_end = 2*1024*1024;
 else
  buffer_memory_end = 1*1024*1024;
 main_memory_start = buffer_memory_end;
#ifdef RAMDISK
 main_memory_start += rd_init(main_memory_start, RAMDISK*1024);
#endif
 mem_init(main_memory_start,memory_end);
 trap_init();
 blk_dev_init();
 chr_dev_init();
 tty_init();
 time_init();
 sched_init();
 buffer_init(buffer_memory_end);
 hd_init();
 floppy_init();
 sti();
 move_to_user_mode();
 if (!fork()) {  /* we count on this going ok */
  init();
 }
/*
 *   NOTE!!   For any other task 'pause()' would mean we have to get a
 * signal to awaken, but task0 is the sole exception (see 'schedule()')
 * as task 0 gets activated at every idle moment (when no other tasks
 * can run). For task0 'pause()' just means we go check if some other
 * task can run, and if not we return here.
 */
 for(;;) pause();
}

void main(void)  /* This really IS void, no error here. */
{   /* The startup routine assumes (well, ...) this */
/*
 * Interrupts are still disabled. Do necessary setups, then
 * enable them
 */
 ROOT_DEV = ORIG_ROOT_DEV;
 drive_info = DRIVE_INFO;
 memory_end = (1<<20) + (EXT_MEM_K<<10);
 memory_end &= 0xfffff000;
 if (memory_end > 16*1024*1024)
  memory_end = 16*1024*1024;
 if (memory_end > 12*1024*1024)
  buffer_memory_end = 4*1024*1024;
 else if (memory_end > 6*1024*1024)
  buffer_memory_end = 2*1024*1024;
 else
  buffer_memory_end = 1*1024*1024;
 main_memory_start = buffer_memory_end;
 ...
}

void main(void)  /* This really IS void, no error here. */
{
#ifdef RAMDISK
 main_memory_start += rd_init(main_memory_start, RAMDISK*1024);
#endif
 mem_init(main_memory_start,memory_end);
 trap_init();
 blk_dev_init();
 chr_dev_init();
 tty_init();
 time_init();
 sched_init();
 buffer_init(buffer_memory_end);
 hd_init();
 floppy_init();
 ...
}

void main(void)  /* This really IS void, no error here. */
{
 sti();
 move_to_user_mode();
 if (!fork()) {  /*we count on this going ok*/
  init();
 }
}

void main(void)  /* This really IS void, no error here. */
{
 /*
 *  NOTE!!   For any other task 'pause()' would mean we have to get a
 * signal to awaken, but task0 is the sole exception (see 'schedule()')
 * as task 0 gets activated at every idle moment (when no other tasks
 * can run). For task0 'pause()' just means we go check if some other
 * task can run, and if not we return here.
 */
 for(;;) pause();
}

ROOT_DEV = ORIG_ROOT_DEV;
drive_info = DRIVE_INFO;

memory_end = (1<<20) + (EXT_MEM_K<<10);
memory_end &= 0xfffff000;
if (memory_end > 16*1024*1024)
 memory_end = 16*1024*1024;
if (memory_end > 12*1024*1024)
 buffer_memory_end = 4*1024*1024;
else if (memory_end > 6*1024*1024)
 buffer_memory_end = 2*1024*1024;
else
 buffer_memory_end = 1*1024*1024;
main_memory_start = buffer_memory_end;

/* these are not to be changed without changing head.s etc */
#define LOW_MEM 0x100000
#define PAGING_MEMORY (15*1024*1024)
#define PAGING_PAGES (PAGING_MEMORY>>12)
#define MAP_NR(addr) (((addr)-LOW_MEM)>>12)
#define USED 100

static long HIGH_MEMORY = 0;

static unsigned char mem_map [ PAGING_PAGES ] = {0,};

void mem_init(long start_mem, long end_mem)
{
 int i;

 HIGH_MEMORY = end_mem;
 for (i=0 ; i<PAGING_PAGES ; i++)
  mem_map[i] = USED;
 i = MAP_NR(start_mem);
 end_mem -= start_mem;
 end_mem >>= 12;
 while (end_mem-->0)
  mem_map[i++]=0;
}

struct desc_struct idt_table[256] = { {0, 0}, };
struct desc_struct {
    unsigned long a,b;
};

void trap_init(void)
{
 int i;

 set_trap_gate(0,&divide_error);
 set_trap_gate(1,&debug);
 set_trap_gate(2,&nmi);
 set_system_gate(3,&int3); /* int3-5 can be called from all */
 set_system_gate(4,&overflow);
 set_system_gate(5,&bounds);
 set_trap_gate(6,&invalid_op);
 set_trap_gate(7,&device_not_available);
 set_trap_gate(8,&double_fault);
 set_trap_gate(9,&coprocessor_segment_overrun);
 set_trap_gate(10,&invalid_TSS);
 set_trap_gate(11,&segment_not_present);
 set_trap_gate(12,&stack_segment);
 set_trap_gate(13,&general_protection);
 set_trap_gate(14,&page_fault);
 set_trap_gate(15,&reserved);
 set_trap_gate(16,&coprocessor_error);
 for (i=17;i<48;i++)
  set_trap_gate(i,&reserved);
 set_trap_gate(45,&irq13);
 outb_p(inb_p(0x21)&0xfb,0x21);
 outb(inb_p(0xA1)&0xdf,0xA1);
 set_trap_gate(39,&parallel_interrupt);
}

#define set_trap_gate(n,addr) \
 _set_gate(&idt[n],15,0,addr)

#define set_system_gate(n,addr) \
 _set_gate(&idt[n],15,3,addr)

#define _set_gate(gate_addr,type,dpl,addr) \
__asm__ ("movw %%dx,%%ax\n\t" \
 "movw %0,%%dx\n\t" \
 "movl %%eax,%1\n\t" \
 "movl %%edx,%2" \
 : \
 : "i" ((short) (0x8000+(dpl<<13)+(type<<8))), \
 "o" (*((char *) (gate_addr))), \
 "o" (*(4+(char *) (gate_addr))), \
 "d" ((char *) (addr)),"a" (0x00080000))

/*
 * NR_REQUEST is the number of entries in the request-queue.
 * NOTE that writes may use only the low 2/3 of these: reads
 * take precedence.
 *
 * 32 seems to be a reasonable number: enough to get some benefit
 * from the elevator-mechanism, but not so much as to lock a lot of
 * buffers when they are in the queue. 64 seems to be too many (easily
 * long pauses in reading when heavy writing/syncing is going on)
 */
#define NR_REQUEST 32
/*
 * Ok, this is an expanded form so that we can use the same
 * request for paging requests when that is implemented. In
 * paging, 'bh' is NULL, and 'waiting' is used to wait for
 * read/write completion.
 */
struct request {
 int dev;  /* -1 if no request */
 int cmd;  /* READ or WRITE */
 int errors;
 unsigned long sector;
 unsigned long nr_sectors;
 char * buffer;
 struct task_struct * waiting;
 struct buffer_head * bh;
 struct request * next;
};

/*
 * The request-struct contains all necessary data
 * to load a nr of sectors into memory
 */
struct request request[NR_REQUEST];

void blk_dev_init(void)
{
 int i;

 for (i=0 ; i<NR_REQUEST ; i++) {
  request[i].dev = -1;
  request[i].next = NULL;
 }
}

void chr_dev_init(void)
{
}

void tty_init(void)
{
 rs_init();
 con_init();
}

void rs_init(void)
{
 set_intr_gate(0x24,rs1_interrupt);
 set_intr_gate(0x23,rs2_interrupt);
 init(tty_table[1].read_q.data);
 init(tty_table[2].read_q.data);
 outb(inb_p(0x21)&0xE7,0x21);
}

/*
 *  void con_init(void);
 *
 * This routine initalizes console interrupts, and does nothing
 * else. If you want the screen to clear, call tty_write with
 * the appropriate escape-sequece.
 *
 * Reads the information preserved by setup.s to determine the current display
 * type and sets everything accordingly.
 */
void con_init(void)
{
 register unsigned char a;
 char *display_desc = "????";
 char *display_ptr;

 video_num_columns = ORIG_VIDEO_COLS;
 video_size_row = video_num_columns * 2;
 video_num_lines = ORIG_VIDEO_LINES;
 video_page = ORIG_VIDEO_PAGE;
 video_erase_char = 0x0720;

 if (ORIG_VIDEO_MODE == 7)   /* Is this a monochrome display? */
 {
  video_mem_start = 0xb0000;
  video_port_reg = 0x3b4;
  video_port_val = 0x3b5;
  if ((ORIG_VIDEO_EGA_BX & 0xff) != 0x10)
  {
   video_type = VIDEO_TYPE_EGAM;
   video_mem_end = 0xb8000;
   display_desc = "EGAm";
  }
  else
  {
   video_type = VIDEO_TYPE_MDA;
   video_mem_end = 0xb2000;
   display_desc = "*MDA";
  }
 }
 else        /* If not, it is color. */
 {
  video_mem_start = 0xb8000;
  video_port_reg = 0x3d4;
  video_port_val = 0x3d5;
  if ((ORIG_VIDEO_EGA_BX & 0xff) != 0x10)
  {
   video_type = VIDEO_TYPE_EGAC;
   video_mem_end = 0xbc000;
   display_desc = "EGAc";
  }
  else
  {
   video_type = VIDEO_TYPE_CGA;
   video_mem_end = 0xba000;
   display_desc = "*CGA";
  }
 }

 /* Let the user known what kind of display driver we are using */

 display_ptr = ((char *)video_mem_start) + video_size_row - 8;
 while (*display_desc)
 {
  *display_ptr++ = *display_desc++;
  display_ptr++;
 }

 /* Initialize the variables used for scrolling (mostly EGA/VGA) */

 origin = video_mem_start;
 scr_end = video_mem_start + video_num_lines * video_size_row;
 top = 0;
 bottom = video_num_lines;

 gotoxy(ORIG_X,ORIG_Y);
 set_trap_gate(0x21,&keyboard_interrupt);
 outb_p(inb_p(0x21)&0xfd,0x21);
 a=inb_p(0x61);
 outb_p(a|0x80,0x61);
 outb(a,0x61);
}

mov [0xB8000],'h'
mov [0xB8002],'e'
mov [0xB8004],'l'
mov [0xB8006],'l'
mov [0xB8008],'o'

#define ORIG_X          (*(unsigned char *)0x90000)
#define ORIG_Y          (*(unsigned char *)0x90001)
void con_init(void) {
    register unsigned char a;
    // 第一部分 获取显示模式相关信息
    video_num_columns = (((*(unsigned short *)0x90006) & 0xff00) >> 8);
    video_size_row = video_num_columns * 2;
    video_num_lines = 25;
    video_page = (*(unsigned short *)0x90004);
    video_erase_char = 0x0720;
    // 第二部分 显存映射的内存区域
    video_mem_start = 0xb8000;
    video_port_reg  = 0x3d4;
    video_port_val  = 0x3d5;
    video_mem_end = 0xba000;
    // 第三部分 滚动屏幕操作时的信息
    origin  = video_mem_start;
    scr_end = video_mem_start + video_num_lines * video_size_row;
    top = 0;
    bottom  = video_num_lines;
    // 第四部分 定位光标并开启键盘中断
    gotoxy(ORIG_X, ORIG_Y);
    set_trap_gate(0x21,&keyboard_interrupt);
    outb_p(inb_p(0x21)&0xfd,0x21);
    a=inb_p(0x61);
    outb_p(a|0x80,0x61);
    outb(a,0x61);
}

/* NOTE! gotoxy thinks x==video_num_columns is ok */
static inline void gotoxy(unsigned int new_x,unsigned int new_y)
{
 if (new_x > video_num_columns || new_y >= video_num_lines)
  return;
 x=new_x;
 y=new_y;
 pos=origin + y*video_size_row + (x<<1);
}

// 定位光标
static inline void gotoxy(unsigned int new_x, unsigned int new_y){}
// 滚屏，即内容向上滚动一行
static void scrup(void){}
// 光标同列位置下移一行
static void lf(int currcons){}
// 光标回到第一列
static void cr(void){}
...
// 删除一行
static void delete_line(void){}

/*
 * Yeah, yeah, it's ugly, but I cannot find how to do this correctly
 * and this seems to work. I anybody has more info on the real-time
 * clock I'd be interested. Most of this was trial and error, and some
 * bios-listing reading. Urghh.
 */

#define CMOS_READ(addr) ({ \
outb_p(0x80|addr,0x70); \
inb_p(0x71); \
})

#define BCD_TO_BIN(val) ((val)=((val)&15) + ((val)>>4)*10)

static void time_init(void)
{
 struct tm time;

 do {
  time.tm_sec = CMOS_READ(0);
  time.tm_min = CMOS_READ(2);
  time.tm_hour = CMOS_READ(4);
  time.tm_mday = CMOS_READ(7);
  time.tm_mon = CMOS_READ(8);
  time.tm_year = CMOS_READ(9);
 } while (time.tm_sec != CMOS_READ(0));
 BCD_TO_BIN(time.tm_sec);
 BCD_TO_BIN(time.tm_min);
 BCD_TO_BIN(time.tm_hour);
 BCD_TO_BIN(time.tm_mday);
 BCD_TO_BIN(time.tm_mon);
 BCD_TO_BIN(time.tm_year);
 time.tm_mon--;
 startup_time = kernel_mktime(&time);
}

long kernel_mktime(struct tm * tm)
{
 long res;
 int year;

 year = tm->tm_year - 70;
/* magic offsets (y+1) needed to get leapyears right.*/
 res = YEAR*year + DAY*((year+1)/4);
 res += month[tm->tm_mon];
/* and (y+2) here. If it wasn't a leap-year, we have to adjust */
 if (tm->tm_mon>1 && ((year+2)%4))
  res -= DAY;
 res += DAY*(tm->tm_mday-1);
 res += HOUR*tm->tm_hour;
 res += MINUTE*tm->tm_min;
 res += tm->tm_sec;
 return res;
}

void sched_init(void)
{
 int i;
 struct desc_struct * p;

 if (sizeof(struct sigaction) != 16)
  panic("Struct sigaction MUST be 16 bytes");
 set_tss_desc(gdt+FIRST_TSS_ENTRY,&(init_task.task.tss));
 set_ldt_desc(gdt+FIRST_LDT_ENTRY,&(init_task.task.ldt));
 p = gdt+2+FIRST_TSS_ENTRY;
 for(i=1;i<NR_TASKS;i++) {
  task[i] = NULL;
  p->a=p->b=0;
  p++;
  p->a=p->b=0;
  p++;
 }
/* Clear NT, so that we won't have troubles with that later on */
 __asm__("pushfl ; andl $0xffffbfff,(%esp) ; popfl");
 ltr(0);
 lldt(0);
 outb_p(0x36,0x43);  /* binary, mode 3, LSB/MSB, ch 0 */
 outb_p(LATCH & 0xff , 0x40); /* LSB */
 outb(LATCH >> 8 , 0x40); /* MSB */
 set_intr_gate(0x20,&timer_interrupt);
 outb(inb_p(0x21)&~0x01,0x21);
 set_system_gate(0x80,&system_call);
}

set_tss_desc(gdt+FIRST_TSS_ENTRY,&(init_task.task.tss));
set_ldt_desc(gdt+FIRST_LDT_ENTRY,&(init_task.task.ldt));

struct tss_struct {
 long back_link; /* 16 high bits zero */
 long esp0;
 long ss0;  /* 16 high bits zero */
 long esp1;
 long ss1;  /* 16 high bits zero */
 long esp2;
 long ss2;  /* 16 high bits zero */
 long cr3;
 long eip;
 long eflags;
 long eax,ecx,edx,ebx;
 long esp;
 long ebp;
 long esi;
 long edi;
 long es;  /* 16 high bits zero */
 long cs;  /* 16 high bits zero */
 long ss;  /* 16 high bits zero */
 long ds;  /* 16 high bits zero */
 long fs;  /* 16 high bits zero */
 long gs;  /* 16 high bits zero */
 long ldt;  /* 16 high bits zero */
 long trace_bitmap; /* bits: trace 0, bitmap 16-31 */
 struct i387_struct i387;
};

int i;
struct desc_struct * p;
p = gdt+2+FIRST_TSS_ENTRY;
for(i=1;i<NR_TASKS;i++) {
 task[i] = NULL;
 p->a=p->b=0;
 p++;
 p->a=p->b=0;
 p++;
}

struct task_struct {
/* these are hardcoded - don't touch */
 long state; /* -1 unrunnable, 0 runnable, >0 stopped */
 long counter;
 long priority;
 long signal;
 struct sigaction sigaction[32];
 long blocked; /* bitmap of masked signals */
/* various fields */
 int exit_code;
 unsigned long start_code,end_code,end_data,brk,start_stack;
 long pid,father,pgrp,session,leader;
 unsigned short uid,euid,suid;
 unsigned short gid,egid,sgid;
 long alarm;
 long utime,stime,cutime,cstime,start_time;
 unsigned short used_math;
/* file system info */
 int tty;  /* -1 if no tty, so it must be signed */
 unsigned short umask;
 struct m_inode * pwd;
 struct m_inode * root;
 struct m_inode * executable;
 unsigned long close_on_exec;
 struct file * filp[NR_OPEN];
/* ldt for this task 0 - zero 1 - cs 2 - ds&ss */
 struct desc_struct ldt[3];
/* tss for this task */
 struct tss_struct tss;
};

/* Clear NT, so that we won't have troubles with that later on */
 __asm__("pushfl ; andl $0xffffbfff,(%esp) ; popfl");
 ltr(0);
 lldt(0);

outb_p(0x36,0x43);  /* binary, mode 3, LSB/MSB, ch 0 */
outb_p(LATCH & 0xff , 0x40); /* LSB */
outb(LATCH >> 8 , 0x40); /* MSB */
set_intr_gate(0x20,&timer_interrupt);
outb(inb_p(0x21)&~0x01,0x21);
set_system_gate(0x80,&system_call);

extern int end;
struct buffer_head * start_buffer = (struct buffer_head *) &end;

void buffer_init(long buffer_end)
{
 struct buffer_head * h = start_buffer;
 void * b;
 int i;

 if (buffer_end == 1<<20)
  b = (void *) (640*1024);
 else
  b = (void *) buffer_end;
 while ( (b -= BLOCK_SIZE) >= ((void *) (h+1)) ) {
  h->b_dev = 0;
  h->b_dirt = 0;
  h->b_count = 0;
  h->b_lock = 0;
  h->b_uptodate = 0;
  h->b_wait = NULL;
  h->b_next = NULL;
  h->b_prev = NULL;
  h->b_data = (char *) b;
  h->b_prev_free = h-1;
  h->b_next_free = h+1;
  h++;
  NR_BUFFERS++;
  if (b == (void *) 0x100000)
   b = (void *) 0xA0000;
 }
 h--;
 free_list = start_buffer;
 free_list->b_prev_free = h;
 h->b_next_free = free_list;
 for (i=0;i<NR_HASH;i++)
  hash_table[i]=NULL;
}

extern int end;
void buffer_init(long buffer_end) {
    struct buffer_head * start_buffer = (struct buffer_head *) &end;
    ...
}

void buffer_init(long buffer_end) {
    struct buffer_head * h = start_buffer;
    void * b = (void *) buffer_end;
    while ( (b -= 1024) >= ((void *) (h+1)) ) {
        ...
        h->b_data = (char *) b;
        h->b_prev_free = h-1;
        h->b_next_free = h+1;
        h++;
    }
    ...
}
