pyspark-ml学习笔记：pyspark下使用xgboost进行分布式训练

MachineLP

发布于 2019-08-29 03:39:52

6K00

代码可运行

文章被收录于专栏：小鹏的专栏小鹏的专栏

运行总次数：0

代码可运行

问题是这样的，如果我们想基于pyspark开发一个分布式机器训练平台，而xgboost是不可或缺的模型，但是pyspark ml中没有对应的API，这时候我们需要想办法解决它。

测试代码：（ (pyspark使用可以参考这个：https://cloud.tencent.com/developer/article/1436179 )）

#!/usr/bin/env python
# -*- coding:utf8 -*-

"""
-------------------------------------------------
   Description :  pyspark测试
   Author :       liupeng
   Date :         2019/7/23
-------------------------------------------------

"""

import os
import sys
import time
import pandas as pd
import numpy as np
from start_pyspark import spark, sc, sqlContext
import pyspark.sql.types as typ
import pyspark.ml.feature as ft
from pyspark.sql.functions import isnan, isnull


import os
os.environ['PYSPARK_SUBMIT_ARGS'] = '--jars xgboost4j-spark-0.72.jar,xgboost4j-0.72.jar pyspark-shell'
# import findspark
# findspark.init()

import pyspark
from pyspark.sql.session import SparkSession
from pyspark.sql.types import *
from pyspark.ml.feature import StringIndexer, VectorAssembler
from pyspark.ml import Pipeline
from pyspark.sql.functions import col

# spark.sparkContext.addPyFile("hdfs:///tmp/rd/lp/sparkxgb.zip")
from sparkxgb import XGBoostEstimator


schema = StructType(
  [StructField("PassengerId", DoubleType()),
    StructField("Survival", DoubleType()),
    StructField("Pclass", DoubleType()),
    StructField("Name", StringType()),
    StructField("Sex", StringType()),
    StructField("Age", DoubleType()),
    StructField("SibSp", DoubleType()),
    StructField("Parch", DoubleType()),
    StructField("Ticket", StringType()),
    StructField("Fare", DoubleType()),
    StructField("Cabin", StringType()),
    StructField("Embarked", StringType())
  ])


df_raw = spark\
  .read\
  .option("header", "true")\
  .schema(schema)\
  .csv("hdfs:///tmp/rd/lp/titanic/train.csv")

df_raw.show(2)
df = df_raw.na.fill(0)

sexIndexer = StringIndexer()\
  .setInputCol("Sex")\
  .setOutputCol("SexIndex")\
  .setHandleInvalid("keep")

cabinIndexer = StringIndexer()\
  .setInputCol("Cabin")\
  .setOutputCol("CabinIndex")\
  .setHandleInvalid("keep")

embarkedIndexer = StringIndexer()\
  .setInputCol("Embarked")\
  .setHandleInvalid("keep")

# .setOutputCol("EmbarkedIndex")\

vectorAssembler = VectorAssembler()\
  .setInputCols(["Pclass", "Age", "SibSp", "Parch", "Fare"])\
  .setOutputCol("features")

xgboost = XGBoostEstimator( featuresCol="features", labelCol="Survival", predictionCol="prediction")

# pipeline = Pipeline().setStages([sexIndexer, cabinIndexer, embarkedIndexer, vectorAssembler, xgboost])
pipeline = Pipeline(stages=[
      vectorAssembler,
      xgboost
      ])


trainDF, testDF = df.randomSplit([0.8, 0.2], seed=24)
trainDF.show(2)


model = pipeline.fit(trainDF)

print (88888888888888888888)


model.transform(testDF).select(col("PassengerId"), col("prediction")).show()

print (9999999999999999999)


'''
# Define and train model
xgboost = XGBoostEstimator(
    # General Params
    nworkers=1, nthread=1, checkpointInterval=-1, checkpoint_path="",
    use_external_memory=False, silent=0, missing=float("nan"),

    # Column Params
    featuresCol="features", labelCol="label", predictionCol="prediction",
    weightCol="weight", baseMarginCol="baseMargin",

    # Booster Params
    booster="gbtree", base_score=0.5, objective="binary:logistic", eval_metric="error",
    num_class=2, num_round=2, seed=None,

    # Tree Booster Params
    eta=0.3, gamma=0.0, max_depth=6, min_child_weight=1.0, max_delta_step=0.0, subsample=1.0,
    colsample_bytree=1.0, colsample_bylevel=1.0, reg_lambda=0.0, alpha=0.0, tree_method="auto",
    sketch_eps=0.03, scale_pos_weight=1.0, grow_policy='depthwise', max_bin=256,

    # Dart Booster Params
    sample_type="uniform", normalize_type="tree", rate_drop=0.0, skip_drop=0.0,

    # Linear Booster Params
    lambda_bias=0.0
)
'''

'''
xgboost_model = xgboost.fit(trainDF)

# Transform test set
xgboost_model.transform(testDF).show()

# Write model/classifier
xgboost.write().overwrite().save("xgboost_class_test")
xgboost_model.write().overwrite().save("xgboost_class_test.model")
'''

start_pyspark.py

#!/usr/bin/env python
# -*- coding:utf8 -*-

"""
-------------------------------------------------
   Description :  模型预测接口
   Author :       liupeng
   Date :         2019/7/23
-------------------------------------------------

"""

import os
import sys

'''
#下面这些目录都是你自己机器的Spark安装目录和Java安装目录
os.environ['SPARK_HOME'] = "/Users/***/spark-2.4.3-bin-hadoop2.7/"

sys.path.append("/Users/***/spark-2.4.3-bin-hadoop2.7/bin")
sys.path.append("/Users/***/spark-2.4.3-bin-hadoop2.7/python")
sys.path.append("/Users/***/spark-2.4.3-bin-hadoop2.7/python/pyspark")
sys.path.append("/Users/***/spark-2.4.3-bin-hadoop2.7/python/lib")
sys.path.append("/Users/***/spark-2.4.3-bin-hadoop2.7/python/lib/pyspark.zip")
sys.path.append("/Users/***/spark-2.4.3-bin-hadoop2.7/lib/py4j-0.9-src.zip")
# sys.path.append("/Library/Java/JavaVirtualMachines/jdk1.8.0_144.jdk/Contents/Home")
os.environ['JAVA_HOME'] = "/Library/Java/JavaVirtualMachines/jdk1.8.0_181.jdk/Contents/Home"
'''

from pyspark.sql import SparkSession, SQLContext
from pyspark import SparkConf, SparkContext
#conf = SparkConf().setMaster("local").setAppName("My App")
conf = SparkConf().setMaster("yarn").setAppName("My App")
sc = SparkContext(conf = conf)
spark = SparkSession.builder.appName('CalculatingGeoDistances').getOrCreate()
sqlContext = SQLContext(sparkContext=sc)

集群提交测试：

nohup /di_software/emr-package/spark-2.4.3-bin-hadoop2.7/bin/spark-submit --master yarn --jars /home/di/liupeng/qdxgboost/xgboost4j-0.72.jar,/home/di/liupeng/qdxgboost/xgboost4j-spark-0.72.jar /home/di/liupeng/qdxgboost/test_xgboost.py > output_spark.log 2>&1 &

主要参考：pyspark xgboost: https://towardsdatascience.com/pyspark-and-xgboost-integration-tested-on-the-kaggle-titanic-dataset-4e75a568bdb （需要 spark2.3之后的版本）

非网格搜索模式下加载和保存模型：

from sparkxgb import XGBoostEstimator, XGBoostClassificationModel
feature_path = '/tmp/rd/lp/model27'
model_path = '/tmp/rd/lp/model28'

xgboost = XGBoostEstimator(featuresCol="features", labelCol="Survival", predictionCol="prediction",
                                   num_round=100)

pipeline = Pipeline(stages=[vectorAssembler])
s_model = pipeline.fit(trainDF)
train_data = s_model.transform( trainDF )
s_model.write().overwrite().save(feature_path)

xgb_model = xgboost.fit( train_data )
xgb_model.write().overwrite().save(model_path)


pipeline = PipelineModel.load(feature_path)
train_data = s_model.transform( trainDF )
model = XGBoostClassificationModel.load( model_path )
res = model.transform( train_data )
print ( 'res:', res.collect() )
