问ReplacementSpan -跨行的“芯片”

EN

val startLine = layout.getLineForOffset(getSpanStart(span))
val endLine = layout.getLineForOffset(getSpanEnd(span))

if (startLine == endLine) // single line span
else // multi-line span

/*
 * Copyright (C) 2018 The Android Open Source Project
 *
 * Licensed under the Apache License, Version 2.0 (the "License");
 * you may not use this file except in compliance with the License.
 * You may obtain a copy of the License at
 *
 *      http://www.apache.org/licenses/LICENSE-2.0
 *
 * Unless required by applicable law or agreed to in writing, software
 * distributed under the License is distributed on an "AS IS" BASIS,
 * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
 * See the License for the specific language governing permissions and
 * limitations under the License.
*/
package com.android.example.text.styling.roundedbg

import android.graphics.Canvas
import android.graphics.drawable.Drawable
import android.text.Layout
import kotlin.math.max
import kotlin.math.min

/**
 * Base class for single and multi line rounded background renderers.
 *
 * @param horizontalPadding the padding to be applied to left & right of the background
 * @param verticalPadding the padding to be applied to top & bottom of the background
 */
internal abstract class TextRoundedBgRenderer(
        val horizontalPadding: Int,
        val verticalPadding: Int
) {
    /**
     * Draw the background that starts at the {@code startOffset} and ends at {@code endOffset}.
     *
     * @param canvas Canvas to draw onto
     * @param layout Layout that contains the text
     * @param startLine the start line for the background
     * @param endLine the end line for the background
     * @param startOffset the character offset that the background should start at
     * @param endOffset the character offset that the background should end at
     */
    abstract fun draw(
        canvas: Canvas,
        layout: Layout,
        startLine: Int,
        endLine: Int,
        startOffset: Int,
        endOffset: Int
    )

    /**
     * Get the top offset of the line and add padding into account so that there is a gap between
     * top of the background and top of the text.
     *
     * @param layout Layout object that contains the text
     * @param line line number
     */
    protected fun getLineTop(layout: Layout, line: Int): Int {
        return layout.getLineTopWithoutPadding(line) - verticalPadding
    }

    /**
     * Get the bottom offset of the line and add padding into account so that there is a gap between
     * bottom of the background and bottom of the text.
     *
     * @param layout Layout object that contains the text
     * @param line line number
     */
    protected fun getLineBottom(layout: Layout, line: Int): Int {
        return layout.getLineBottomWithoutPadding(line) + verticalPadding
    }
}

/**
 * Draws the background for text that starts and ends on the same line.
 *
 * @param horizontalPadding the padding to be applied to left & right of the background
 * @param verticalPadding the padding to be applied to top & bottom of the background
 * @param drawable the drawable used to draw the background
 */
internal class SingleLineRenderer(
    horizontalPadding: Int,
    verticalPadding: Int,
    val drawable: Drawable
) : TextRoundedBgRenderer(horizontalPadding, verticalPadding) {

    override fun draw(
        canvas: Canvas,
        layout: Layout,
        startLine: Int,
        endLine: Int,
        startOffset: Int,
        endOffset: Int
    ) {
        val lineTop = getLineTop(layout, startLine)
        val lineBottom = getLineBottom(layout, startLine)
        // get min of start/end for left, and max of start/end for right since we don't
        // the language direction
        val left = min(startOffset, endOffset)
        val right = max(startOffset, endOffset)
        drawable.setBounds(left, lineTop, right, lineBottom)
        drawable.draw(canvas)
    }
}

/**
 * Draws the background for text that starts and ends on different lines.
 *
 * @param horizontalPadding the padding to be applied to left & right of the background
 * @param verticalPadding the padding to be applied to top & bottom of the background
 * @param drawableLeft the drawable used to draw left edge of the background
 * @param drawableMid the drawable used to draw for whole line
 * @param drawableRight the drawable used to draw right edge of the background
 */
internal class MultiLineRenderer(
    horizontalPadding: Int,
    verticalPadding: Int,
    val drawableLeft: Drawable,
    val drawableMid: Drawable,
    val drawableRight: Drawable
) : TextRoundedBgRenderer(horizontalPadding, verticalPadding) {

    override fun draw(
        canvas: Canvas,
        layout: Layout,
        startLine: Int,
        endLine: Int,
        startOffset: Int,
        endOffset: Int
    ) {
        // draw the first line
        val paragDir = layout.getParagraphDirection(startLine)
        val lineEndOffset = if (paragDir == Layout.DIR_RIGHT_TO_LEFT) {
            layout.getLineLeft(startLine) - horizontalPadding
        } else {
            layout.getLineRight(startLine) + horizontalPadding
        }.toInt()

        var lineBottom = getLineBottom(layout, startLine)
        var lineTop = getLineTop(layout, startLine)
        drawStart(canvas, startOffset, lineTop, lineEndOffset, lineBottom)

        // for the lines in the middle draw the mid drawable
        for (line in startLine + 1 until endLine) {
            lineTop = getLineTop(layout, line)
            lineBottom = getLineBottom(layout, line)
            drawableMid.setBounds(
                (layout.getLineLeft(line).toInt() - horizontalPadding),
                lineTop,
                (layout.getLineRight(line).toInt() + horizontalPadding),
                lineBottom
            )
            drawableMid.draw(canvas)
        }

        val lineStartOffset = if (paragDir == Layout.DIR_RIGHT_TO_LEFT) {
            layout.getLineRight(startLine) + horizontalPadding
        } else {
            layout.getLineLeft(startLine) - horizontalPadding
        }.toInt()

        // draw the last line
        lineBottom = getLineBottom(layout, endLine)
        lineTop = getLineTop(layout, endLine)

        drawEnd(canvas, lineStartOffset, lineTop, endOffset, lineBottom)
    }

    /**
     * Draw the first line of a multiline annotation. Handles LTR/RTL.
     *
     * @param canvas Canvas to draw onto
     * @param start start coordinate for the background
     * @param top top coordinate for the background
     * @param end end coordinate for the background
     * @param bottom bottom coordinate for the background
     */
    private fun drawStart(canvas: Canvas, start: Int, top: Int, end: Int, bottom: Int) {
        if (start > end) {
            drawableRight.setBounds(end, top, start, bottom)
            drawableRight.draw(canvas)
        } else {
            drawableLeft.setBounds(start, top, end, bottom)
            drawableLeft.draw(canvas)
        }
    }

    /**
     * Draw the last line of a multiline annotation. Handles LTR/RTL.
     *
     * @param canvas Canvas to draw onto
     * @param start start coordinate for the background
     * @param top top position for the background
     * @param end end coordinate for the background
     * @param bottom bottom coordinate for the background
     */
    private fun drawEnd(canvas: Canvas, start: Int, top: Int, end: Int, bottom: Int) {
        if (start > end) {
            drawableLeft.setBounds(end, top, start, bottom)
            drawableLeft.draw(canvas)
        } else {
            drawableRight.setBounds(start, top, end, bottom)
            drawableRight.draw(canvas)
        }
    }
}

/**
 * A TextView that can draw rounded background to the portions of the text. See
 * [TextRoundedBgHelper] for more information.
 *
 * See [TextRoundedBgAttributeReader] for supported attributes.
 */
class RoundedBgTextView : AppCompatTextView {

    private val textRoundedBgHelper: TextRoundedBgHelper

    @JvmOverloads
    constructor(
        context: Context,
        attrs: AttributeSet? = null,
        defStyleAttr: Int = android.R.attr.textViewStyle
    ) : super(context, attrs, defStyleAttr) {
        val attributeReader = TextRoundedBgAttributeReader(context, attrs)
        textRoundedBgHelper = TextRoundedBgHelper(
            horizontalPadding = attributeReader.horizontalPadding,
            verticalPadding = attributeReader.verticalPadding,
            drawable = attributeReader.drawable,
            drawableLeft = attributeReader.drawableLeft,
            drawableMid = attributeReader.drawableMid,
            drawableRight = attributeReader.drawableRight
        )
    }

    override fun onDraw(canvas: Canvas) {
        // need to draw bg first so that text can be on top during super.onDraw()
        if (text is Spanned && layout != null) {
            canvas.withTranslation(totalPaddingLeft.toFloat(), totalPaddingTop.toFloat()) {
                textRoundedBgHelper.draw(canvas, text as Spanned, layout)
            }
        }
        super.onDraw(canvas)
    }
}

/**
 * Helper class to draw multi-line rounded background to certain parts of a text. The start/end
 * positions of the backgrounds are annotated with [android.text.Annotation] class. Each annotation
 * should have the annotation key set to **rounded**.
 *
 * i.e.:
 * ```
 *    <!--without the quotes at the begining and end Android strips the whitespace and also starts
 *        the annotation at the wrong position-->
 *    <string name="ltr">"this is <annotation key="rounded">a regular</annotation> paragraph."</string>
 * ```
 *
 * **Note:** BiDi text is not supported.
 *
 * @param horizontalPadding the padding to be applied to left & right of the background
 * @param verticalPadding the padding to be applied to top & bottom of the background
 * @param drawable the drawable used to draw the background
 * @param drawableLeft the drawable used to draw left edge of the background
 * @param drawableMid the drawable used to draw for whole line
 * @param drawableRight the drawable used to draw right edge of the background
 */
class TextRoundedBgHelper(
    val horizontalPadding: Int,
    verticalPadding: Int,
    drawable: Drawable,
    drawableLeft: Drawable,
    drawableMid: Drawable,
    drawableRight: Drawable
) {

    private val singleLineRenderer: TextRoundedBgRenderer by lazy {
        SingleLineRenderer(
            horizontalPadding = horizontalPadding,
            verticalPadding = verticalPadding,
            drawable = drawable
        )
    }

    private val multiLineRenderer: TextRoundedBgRenderer by lazy {
        MultiLineRenderer(
            horizontalPadding = horizontalPadding,
            verticalPadding = verticalPadding,
            drawableLeft = drawableLeft,
            drawableMid = drawableMid,
            drawableRight = drawableRight
        )
    }

    /**
     * Call this function during onDraw of another widget such as TextView.
     *
     * @param canvas Canvas to draw onto
     * @param text
     * @param layout Layout that contains the text
     */
    fun draw(canvas: Canvas, text: Spanned, layout: Layout) {
        // ideally the calculations here should be cached since they are not cheap. However, proper
        // invalidation of the cache is required whenever anything related to text has changed.
        val spans = text.getSpans(0, text.length, Annotation::class.java)
        spans.forEach { span ->
            if (span.value.equals("rounded")) {
                val spanStart = text.getSpanStart(span)
                val spanEnd = text.getSpanEnd(span)
                val startLine = layout.getLineForOffset(spanStart)
                val endLine = layout.getLineForOffset(spanEnd)

                // start can be on the left or on the right depending on the language direction.
                val startOffset = (layout.getPrimaryHorizontal(spanStart)
                    + -1 * layout.getParagraphDirection(startLine) * horizontalPadding).toInt()
                // end can be on the left or on the right depending on the language direction.
                val endOffset = (layout.getPrimaryHorizontal(spanEnd)
                    + layout.getParagraphDirection(endLine) * horizontalPadding).toInt()

                val renderer = if (startLine == endLine) singleLineRenderer else multiLineRenderer
                renderer.draw(canvas, layout, startLine, endLine, startOffset, endOffset)
            }
        }
    }
}

<com.android.example.text.styling.roundedbg.RoundedBgTextView
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:text="@string/my_annotated_text"
    app:roundedTextDrawable="@drawable/rounded"
    app:roundedTextDrawableLeft="@drawable/rounded_left"
    app:roundedTextDrawableMid="@drawable/rounded_mid"
    app:roundedTextDrawableRight="@drawable/rounded_right" />

<string name="my_annotated_text">"this is <annotation key="rounded">a regular</annotation> paragraph."</string>

val span = SpannableString("this is my text value that needs to be spanned")
span.setSpan(Annotation("", "rounded"), 0, 10, Spannable.SPAN_EXCLUSIVE_EXCLUSIVE)
span.setSpan(Annotation("", "rounded"), 15, 19, Spannable.SPAN_EXCLUSIVE_EXCLUSIVE)
